VCR and Audio Cassette Motors

Universal VCR Loading Motor


Fits most brands and models of VCRs including Broksonic, Curtis-Mathes, Daewoo, Emerson, Fisher, 1990's Funai's, GE, Goldstar, Hitachi, JC Penney, JVC, Lloyds, Magnavox, Mitsubishi, Montgomery Ward, NEC, Orion, Panasonic, Philco, Philips, Quasar, RCA, Realistic, Samsung, Sanyo, Scott, Sears, Sharp, Sylvania, 1990's Symphonics, 1990's Toshibas, and Zenith. Exceptions are Sony, late 1980's Toshiba models, and late 1980's XR-1000, Multitech and Symphonic. Reuse existing pulley from old motor - shaft size is standard.

MXN13FB12F        $13.95



Toshiba VCR Loading Motor

Fits late 1980's model Toshiba VCRs which have the loading motor on the top side of the chassis, in the right rear corner. Also fits late 1980's XR-1000, Multitech and Symphonic. Reuse existing pulley from old motor - shaft size is standard.

DMM-C013        $13.95


Audio Cassette Motors

Single Speed Motors
(for Single Deck Machines)
These motors work in most single-speed decks.   Match voltage and direction of rotation with your existing motor.

$10.95 each

(*Direction refers to the direction of rotation of the shaft, when facing the motor at the shaft end. CW means clockwise, and CCW means counterclockwise.  All of these motors are 2400 RPM.)

(For two-speed motors on dual deck machines, see below)

Part No. Voltage Direction* Order
EG530AD-6F
$10.95
6 volts CW*
EG530AD-6B
$10.95
6 volts CCW*
EG530AD-9F
$10.95
9 volts CW*

EG530AD-9B
$10.95
9 volts CCW*

EG530AD-2F
$10.95
12 volts CW*

EG530AD-2B
$8.95
12 volts CCW*




Dual Speed Motors
(for Dual Deck Machines)

NOTE:  Unlike the single speed motors, these motors are NOT universal.   Your existing motor needs to have the identical part number as shown below, or it is very likely that the replacement motor will not work correctly.
$12.95 each

(*Direction refers to the direction of rotation of the shaft, when facing the motor at the shaft end.
CW means clockwise, and CCW means counterclockwise.)

Model Specs Price Order
EG530YD-2B 12V CCW,
2000/4000 RPM
$12.95




EG530KD-2B 12V CCW,
1600/3200 RPM
$12.95

EG530KD-2F 12V CW,
1600/3200 RPM
$12.95

EG530KD-9B 9V CCW,
1600/3200 RPM
$12.95

EG530KD-9F 9V CW,
1600/3200 RPM
$12.95

EG530YD-9BH 9V CCW,
2000/4000 RPM
$12.95
