Plugs


>
  1/4" Plugs


Click on photo for
 larger view
PLUG, 1/4", NEUTRIK/REAN MONO, SOLDER TERMINALS, STRAIN RELIEF
Heavy-duty machined copper alloy handle, tip, and body for unsurpassed ruggedness. Bright nickel plating on exterior surfaces will not chip or corrode. Solder terminals are tin electroplated for ease of soldering. One-piece tip rod staked into tip terminal to ensure electrical continuity. Heavy-duty cable clamp provides secure strain relief.   Very similar to Switchcraft 280.
Part #NYS224
$2.79



Click on photo for
 larger view
PLUG, 1/4", NEUTRIK/REAN STEREO, SOLDER TERMINALS, STRAIN RELIEF
Heavy-duty machined copper alloy handle, tip, and body for unsurpassed ruggedness. Bright nickel plating on exterior surfaces will not chip or corrode. Solder terminals are tin electroplated for ease of soldering. One-piece tip rod staked into tip terminal to ensure electrical continuity. Heavy-duty cable clamp provides secure strain relief.   Very similar to Switchcraft 297.
Part #NYS228
$2.99



Click on photo for
 larger view
PLUG, 1/4", NEUTRIK/REAN MONO, SOLDER TERMINALS, STRAIN RELIEF, EXTRA LARGE BODY
Commercial wide-body 1/4" mono phone plugs designed specifically for use with heavy-gauge speaker wire. Features machined turned brass construction, large cable clamp and solder tabs that accept up to 12 gauge wire. 8mm cable entry. • Nickel Shell • Mfg. #NYS225
Part #NYS225
$4.99


Click on photo for
 larger view
PLUG, 1/4", MONO, RIGHT ANGLE, SOLDER TERMINALS, STRAIN RELIEF
1/4" Mono 3-Conductor Right Angle Flat-Back Plug (Similar to Switchcraft Type 228).
Used for a variety of applications where Tip/Sleeve connections are needed and space is at a premium.   Frequently found on single Fender™ footswitch boxes. Includes Hardware.
Part #P-195
$4.29


Click on photo for
 larger view
PLUG, 1/4", STEREO, RIGHT ANGLE, SOLDER TERMINALS, STRAIN RELIEF
1/4" Stereo 3-Conductor Right Angle Flat-Back Plug (Similar to Switchcraft Type 238).    Excellent quality construction - almost indistinguishable from the 238.  Used for a variety of applications where Tip/Ring/Sleeve connections are needed and space is at a premium.   Frequently found on footswitch boxes - particularly the footswitch box on the Fender™ Reissue 65 Twin and Deluxe Reverb amps.  Includes Hardware.
Part #P-305
$4.95


Click on photo for
 larger view
PLUG, 1/4", MONO, RIGHT ANGLE, SOLDER TERMINALS, STRAIN RELIEF
Similar to the Switchcraft 226 right-angle plug.   Nickel plated copper alloy.   2-conductor right-angle phone plug, solder terminals.
Part #P-287
$3.95


Click on photo for
 larger view
F-CAP
This is the frequently lost Fender-logo plastic cap that snaps onto the 1/4" right-angle speaker plug on vintage Blackface and Silverface Fender™ amplifiers from the 1960s and 1970s.  Exact fit and replacement.  For the plug, see the P-055 plug below.
Part #F-CAP
$5.99


Click on photo for
 larger view
Fender™ Right-Angle Speaker Plug
Replacement Fender™ right-angle speaker plug on vintage Blackface and Silverface Fender™ amplifiers from the 1960s and 1970s.   Uses the F-CAP, above (not included - sold separately).  Note:  Requires a very hot soldering iron used for minimal time when soldering to the case or center post of the plug.   Heat applied for an extended time will damage the plug.
Part #P-055
$11.99

  Quick Connects


Click on photo for
 larger view

1/4" FULLY INSULATED FEMALE QUICK CONNECT TERMINAL CONNECTOR - 14GA or 16GA wire.
For connections to terminals on PC boards in many amplifiers.  For 1/4" width terminals.   Fully insulated for safety.   Blue - designed for 14-16ga wire.    Requires standard crimp terminal tool for proper wire connection.   Pack of 12 connectors.
Part #FC-6225

$1.99
(for 1 dozen connectors)




Click on photo for
 larger view

1/4" FULLY INSULATED FEMALE QUICK CONNECT TERMINAL CONNECTOR - 18GA to 22GA wire.
For connections to terminals on PC boards in many amplifiers.   For 1/4" width terminals.  Fully insulated for safety.   Red - designed for 18-22ga wire.    Requires standard crimp terminal tool for proper wire connection.   Pack of 12 connectors.
Part #FC-6125

$1.99
(for 1 dozen connectors)




Click on photo for
 larger view

3/16" FEMALE QUICK CONNECT TERMINAL CONNECTOR - 14GA or 16GA wire.
For connections to speakers in many amplifiers.   For 1/4" width terminals.   Blue - designed for 14-16ga wire.    Requires standard crimp terminal tool for proper wire connection.   Pack of 12 connectors.
Part #FC-1250

$1.69
(for 1 dozen connectors)




Click on photo for
 larger view

3/16" FEMALE QUICK CONNECT TERMINAL CONNECTOR - 18GA-22GA
For connections to speakers in many amplifiers.   For 3/16" width terminals. Red - designed for 18-22ga wire.    Requires standard crimp terminal tool for proper wire connection.   Pack of 12 connectors.
Part #FC-1150

$1.49
(for 1 dozen connectors)




Click on photo for
 larger view

1/4" FEMALE QUICK CONNECT TERMINAL CONNECTOR - 14GA or 16GA wire.
For connections to speakers in many amplifiers.   For 1/4" width terminals.  Blue - designed for 14-16ga wire.    Requires standard crimp terminal tool for proper wire connection.   Pack of 12 connectors.
Part #FC-1225

$1.69
(for 1 dozen connectors)




Click on photo for
 larger view

1/4" FEMALE QUICK CONNECT TERMINAL CONNECTOR - 18-22GA WIRE
For connections to speakers in many amplifiers.   For 1/4" width terminals.  Blue - designed for 18-22ga wire.    Requires standard crimp terminal tool for proper wire connection.   Pack of 12 connectors.
Part #FC-1125

$1.49
(for 1 dozen connectors)





Instrument
Cables







Click on photo for
 larger view
Revisit™ INSTRUMENT CABLE 15 FEET
Revisit 1/4" musical instrument cables provide the reliable link that lets you concentrate on a great performance. Also great for unbalanced line level interconnection, too.   15 feet long, 1/4" straight connectors.
  • 22 AWG oxygen-free copper stranded center conductor for maximum signal transfer
  • Coaxial construction and copper 95% braided shield reduce noise
  • Premium jacket materials provide ease of handling and long service life
  • Gold plated straight 1/4" connectors for long-term conductivity
  • Part #GCB-15

    $11.99



    Speaker Harnesses







    Click on photo for
     larger view
    Revisit™ SPEAKER HARNESS
    Replacement right-angle plug with 34" cable and 3/16" fast-on connectors.    Used to replace speaker cable in most combo amplifiers where the speakers are connected to the amplifier chassis via a 1/4" jack and plug.   18ga black zip cord, right-angle plug and fast-on connectors for attachment to one speaker.
    Part #SCH-280
    $6.99



    Click on photo for
     larger view
    Revisit™ 18 GAUGE COPPER BONDED RED/BLACK ZIP CORD
    Make low-cost, efficient speaker cables with this color-coded 18 gauge dual zip cord.   Red and black for easy polarity identification.  Resistance is 0.0097 ohms/ft.  Automotive grade "GPT" PVC insulation, oil and gas resistant, rated for -20 deg F to +160 deg F. Also perfect for bias testers, radio, home theatre, automotive, stereo, robotics, and model train applications.   Priced per foot, sold in lengths from 1 foot to 50 feet.
    Part #RBZ-18
    $0.32
    (priced per foot)


    Feet (1-50):


    Click on photo for
     larger view

    SPEAKER JUMPER CABLE
    polyvinyl insulated silver plated copper speaker wire, 18 gauge, twisted pair, black and white.   Terminated at each end in standard 3/16" speaker fast-on connectors.   Great for connecting speakers in parallel in 2x12 or 4x12 cabinets.   24 inches (61 cm) long.   Made in USA.
    Part #SJ-150

    $5.99





    Click on photo for
     larger view
    Revisit™ F1 to F2 Faston Push-on Terminal Adapters
    Used to change the size of speaker terminals from .187" (3/16") to .250" (1/4").  Also used to change the size of some PC board connectors.    Female .187" to male .250"
    Part #F1F2
    $1.89
    (Set of 2 Adapters)




    Click on photo for
     larger view
    Revisit™ F2 to F1 Faston Push-on Terminal Adapters
    Used to change the size of speaker terminals from .250" (1/4") to .187" (3/16").  Also used to change the size of some PC board connectors.   Female .250" to male .187"
    Part #F2F1
    $1.89
    (Set of 2 Adapters)




    Click on photo for
     larger view
    Revisit™ Fender™ STYLE "SPIDER" DISTRIBUTION CONNECTOR FOR BLACKFACE SPIDER SPEAKER HARNESSES
    Replacement vintage style Spider distribution board, used to tie together speaker wires in some vintage blackface Fender™ amps, particularly the vintage blackface Super Reverb.   Also found in some blackface 2-speaker amps, including the Pro Reverb, Twin Reverb, Vibrolux Reverb, and Vibroverb amplifiers from the 60s.

    Part #FS
    J-428
    $5.99



    Other Connectors






    Click on photo for
     larger view

    Fender™ Style RCA Plug from Switchcraft
    This is the original Switchcraft RCA plug used on vintage Fender amps for footswitch and reverb in / out connections. For cable up to 0.125" (3.18mm) diameter.
    Part #P-3501MX

    $1.39




    Click on photo for
    larger view

    Fender™ RCA VIBRATO SHORTING PLUG by Revisit™ - GOLD-PLATED.   Did you know that on vintage Fender™ amps (Blackface, Silverface), the reverb will work without a footswitch plugged in, but the vibrato will not?   This handy-dandy little RCA shorting plug will fix that problem, if you do not own or prefer not to use a footswitch on your vintage 60s or 70s Fender™ amp.   This version is made of gold-plated brass for a low resistance connection and highest immunity to oxidation.  Just plug this little RCA plug gadget into the vibrato footswitch jack on the back panel, and your vibrato will come alive.    Turn the intensity knob to zero to cut out the vibrato when this plug is inserted.
    Part #FSP-200

    $2.50




    Click on photo for
    larger view

    POWER BARREL PLUG
    Replacement barrel power plug for many AC Adapters.  Connector is the popular 2.1mm x 5.5mm barrel plug found on many Adapters.   Soldering required to attach to cable.
    Part #BP-573

    $0.99





    DIN Plugs






    Click on photo for
     larger view

    DIN PLUG, MALE, 5-PIN
    Rubber sleeve and strain-relief.  Black in color.   Replacement for MIDI connector.
    Part SD-50

    $3.95


    Click on photo for
     larger view

    DIN PLUG, MALE, 6-PIN
    Rubber sleeve and strain-relief.  Gray in color.   Replacement for 6-pin connector on many Peavey footswitches.   Mates with the J-520 chassis-mount jack, found on this page
    Part SD-60

    $3.95


    Click on photo for
     larger view

    DIN PLUG, MALE, 7-PIN
    Rubber sleeve and strain-relief.  Gray in color.   Replacement for 7-pin connector on many Peavey footswitches.   Mates with the J-516 chassis-mount jack, found on this page
    Part SD-70

    $3.95
