EFFECTS PEDAL POWER SUPPLY 9V DC, 1.6 amps.
Input voltage from 100V AC to 240V AC. Output 9 volts DC,
1600mA, fully regulated. Connector is a 2.1mm inner
diameter, center negative, outside sleeve positive. Perfect for
most pedals which are 9V battery powered. This compact
supply will power up to 10 pedals (assuming each pedal requires 160mA or
less). For powering
 multiple
pedals, see the DCC10X8 cable, below.
Part #PPS-916 |
$14.95 | |
|
Click on photo for
larger view |
REVISIT
PEDAL POWER DAISY CHAIN CABLE
Connect up to 10 Pedals with this Power Cable from a single power supply.
This daisy chain is the industry standard 2.1mm size. There are 1 in and 10
outs. It is well made, has right angle plugs and built with 22AWG wire.
Total length is 8 feet. The amperage capacity of the power supply you use
with this cable needs to be at least as large as the sum of all of the current
requirements of your pedals. For example, if each pedal requires
160mA (or 0.16 amps), the power supply needs to be capable of at least 10 x 0.16
= 1.6 amps (or 1600mA)
Part #DCC10X8 |
$11.95 |
|
|
Click on photo for
larger view |
REVISIT
POLARITY REVERSING ADAPTER CABLE
Fixes the frustrating problem of having a power supply designed for "center
pin positive" and a pedal which requires "center pin negative". Or
vice-versa! This ingenious adapter cable reverses the center pin
with the outside ring, allowing you to successfully use a "backwards" pedal with
your pedal power supply. The connectors are the popular 2.1mm x 5.5mm
size. 5 inches long.
Part #PRC-129 |
$2.29 |
|
Click on photo for
larger view |
POWER CONNECTOR
ADAPTER 2.1mm to 2.5mm
The
two most common connectors for AC adapters are 2.1mm x 5.5mm and 2.5mm x
5.5mm. The outside diameter of these connectors are
identical, but one uses a larger pin than the other, and therefore they
are not compatible. This adapter has a 2.1mm pin in the
back, with a 2.5mm hole in the front, for cases where the pin in your
pedal is just a tiny bit too large for the adapter.
Part #195-3591 |
$2.99 | |
Click on photo for
larger view |
POWER CONNECTOR
ADAPTER 2.5mm to 2.1mm
The two
most common connectors for AC adapters are 2.1mm x 5.5mm and 2.5mm x 5.5mm.
The outside diameter of these connectors are identical, but one uses a
larger pin than the other, and therefore they are not compatible.
This adapter has a 2.5mm pin in the back, with a 2.1mm hole in the front,
for cases where the pin in your pedal is just a tiny bit too small for the
adapter connector, and your power is intermittent when you move the adapter
cable.
Part
#195-3604 |
$2.99 | |
Click on photo for
larger view |
DC POWER JACK
Handy way to add a power jack for an AC/DC adapter to an existing devices.
Connector fits the popular 2.1mm x 5.5mm barrel plug found on many adapters.
Normally closed switch, so that an internal battery may be switched on or
off automatically as the adapter is connected. Plastic housing
isolates both conductors, so it may be used for either center positive or
center negative adapters. Fits 1/2" chassis hole.
Part #J-750 |
$1.49 | |
|
Click on photo for
larger view |
DC POWER JACK
Replacement Barrel DC power jack for many
pedals, keyboards, etc which use a PC board mounted DC power jack.
Connector fits the popular 2.1mm x 5.5mm barrel plug found on many adapters.
Normally closed switch, so that an internal battery may be switched on or off
automatically as the adapter is connected. Plastic housing isolates
both conductors, so it may be used for either center positive or center negative
adapters.
Part #BJK-118 |
$0.99 |
|
|
Click on photo for
larger view |
1/8" MINI JACK
Switched two-conductor 1/8" mini jack.
Exact replacement for the DC power jack used in the vintage Electro-Harmonix Big
Muff and Small Stone, Proco Rat Big Box Reissue and others.
Part #J-218 |
$0.99 |
|
|
Click on photo for
larger view |
POWER BARREL PLUG
Replacement barrel power plug for many AC
adapters. Connector is the popular 2.1mm x 5.5mm barrel plug found on many
adapters. Soldering required to attach to cable.
Part #BP-573 |
$0.99 |
|
Click on photo for
larger view |
9V BATTERY CLIP.
Commonly found in effects boxes. Simple, yet durable
construction. 5-3/4" red and black leads.
Part #9VBC |
$0.45 |
|
