Fender™ Vintage Amp Restoration
Parts - Original Brownface
(Blonde & Brown Tolex - 1959-1963)

We carry a complete selection of Fender™ Amplifier Parts to restore your original vintage brownface/blonde amp from 1959-1963.

Jacks    Jewels    Handles   Hardware    Knobs    Lamps    Capacitor Cover

Corners    Capacitors    Capacitor Sets     Pots    Power Cords

Reverb Parts     Switches    Plugs & Harnesses    Resistors    Fuse Holders

 Wheels/Casters


Fender™ Hardware
(Also see our complete line of hardware)



Click on photo for
larger view
TUBE SHIELD, BAYONET "PUSH AND TWIST" TYPE, ALUMINUM, 1 15/16" TALL WITH 9-PIN TUBE SOCKET AND INTEGRAL TUBE SHIELD BASE .  Spring in top of shield fits over the tube.  Fits 12AX7A and similarly sized preamp tubes.   9-Pin tube socket is made of sturdy Micalex.   Replacement for Fender™ and many other brands.  Holes in base spaced 1 1/8" apart.   Requires 3/4" hole in chassis.  Solder lugs for wire connection to tube socket. Shield, base and socket
Part #TS-370
$4.99


Click on photo for
larger view
TUBE SHIELD, BAYONET "PUSH AND TWIST" TYPE, ALUMINUM, 1 15/16" TALL.  Includes new base, if needed.  Spring in top of shield fits over the tube.  Fits 12AX7A and similarly sized preamp tubes. Replacement for Fender™ and many other brands.  Holes in base spaced 1 1/8" apart.  Shield and base only - socket not included.

Part #TS-325S
$2.29


Click on photo for
larger view
TUBE SHIELD, BAYONET "PUSH AND TWIST" TYPE, ALUMINUM, 1 15/16" TALL, SET OF 6.  Includes new bases, if needed.  Spring in top of shield fits over the tube.  Fits 12AX7A and similarly sized preamp tubes. Replacement for Fender™ and many other brands.  Holes in base spaced 1 1/8" apart.   This is a great kit to replaced all 6 of the tube shields in many Fender™ amps with 6 preamp tubes.  Shield and base only - socket not included.

Part #TS-325S-6
$12.95


(TUBE NOT INCLUDED)

Click on photo for
larger view

Revisit™ PRE-AMP TUBE DAMPER RINGS.   Use two (or three) of these rings around a pre-amp tube to reduce noise and microphonics.  An economical alternative to more expensive tube dampers.   Will withstand high temperatures of pre-amp tubes, reusable when you change tubes.   Set of 6 rings - will equip either 2 or 3 tubes, depending on the number of rings you choose for each tube. Note: Tube shields will not fit over the damper rings, and must be removed from the tubes.   These dampers are NOT for 9-pin power tubes, such as the EL84 or 6BQ5.
Part #PTD-6
$4.95
(Set of 6 rings)


Click on photo for
larger view
TUBE RETAINER WITH GRIP TEETH, DESIGNED FOR OCTAL TUBES WITH PHENOLIC BASE SUCH AS 6L6 OR EL34.   Used in Fender™ and many other amps.     1 1/2" mounting centers.  Made by Belton.  Fender part number 099072500.
Part #TC-142
$2.25


Click on photo for
larger view
OCTAL TUBE KEYWAY, SET OF 2
If you have a cherished octal power tube or rectifier with a broken keyway, here is a great solution. By cleaning the remainder of the broken keyway from the tube base and properly installing this keyway replacement (a little dab of silicone sealant works great to hold it in place), your tube can safely be reinstalled into your equipment.   These great tube-savers are sold in sets of 2.   Note:  When using an adhesive to secure the keyway to the tube base, DO NOT use a water-based glue.   Silicone sealant (RTV) which is acryllic-based or butyl-based is fine.   Latex sealant or hot-glue is NOT.
Part #OTK8-2
$8.99
(for a set of 2 tube keyways)


Click on photo for
larger view
OCTAL TUBE BASE, SOLD INDIVIDUALLY
Octal tube bases are used to construct tube socket savers, solid-state rectifiers, bias probes, etc.   8-pin plug with room inside the base for circuitry and wiring.  Sold individually.
Part #OTB-100

$3.99 ea


Click on photo for
larger view
TUBE SOCKET, OCTAL 8-PIN, commonly used with the Octal Tube Base to build bias probes, tube socket savers, tube extenders, etc.   This socket has no mounting bracket.
Part #TS-8-810
$4.40


Click on photo for
larger view
PHENOLIC TUBE SOCKET FOR OCTAL TUBES.  EXACT REPLACEMENT FOR VINTAGE FENDER, VINTAGE Marshall™ (including the JCM900 Series), and many others.    Fits 6L6, EL34, 6V6 output tubes, and 5U4, 5Y3, and GZ34 rectifier tubes.   For 1" to 1 1/8" hole.  Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/2" apart.  Unlike some phenolic tube sockets on the market, this one fits the 1" hole found in most vintage Fenders.
Part #TS-8-600
$4.50


Click on photo for larger view

CERAMIC 8-PIN WIRED OUTPUT TUBE OR RECTIFIER TUBE SOCKET, crimped bracket, bottom mount 1 1/4", top mount 1" to 1 1/8", 1 1/2" mounting centers, 1" to 1 1/4" chassis hole.  Fits 6L6, EL34, 6V6 output tubes, and 5U4, 5Y3, and GZ34 rectifier tubes.  Click here for additional specs.   Fender part number 0990724000, or 023580.
Part #TS-8-807W

$3.95


Click on photo for
larger view
FENDER STYLE MICALEX TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  INCLUDES INTEGRAL BASE FOR TWIST-LOCK TUBE SHIELD.        Fits 12AX7, 12AU7, 12AT7, etc.   Sturdy Micalex construction, for 3/4"  hole.  Solder tabs for wire connections.   Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TS-325S tube shield, or vintage Fender tube shields.   Used in Fender vintage Blonde, Brownface, Blackface, Silverface and some early Rivera designs.   Also applicable to early Marshall designs.  Fender part number 0023606049.
Part #TS-9-700
$4.49


Click on photo for
larger view
6-PACK OF FENDER STYLE MICALEX TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  INCLUDES INTEGRAL BASE FOR TWIST-LOCK TUBE SHIELD.      Fits 12AX7, 12AU7, 12AT7, etc.   Sturdy Micalex construction, for 3/4"  hole.  Solder tabs for wire connections.   Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TS-325S tube shield, or vintage Fender tube shields.   Used in Fender vintage Blonde, Brownface, Blackface, Silverface and some early Rivera designs.   Also applicable to early Marshall designs.   Pack of 6 tube sockets.  Mounting screws not included - recommend the SC-410-6 screws (2 packs of 6 screws needed for 6 tube sockets).  It is also possible to use 1/8 inch pop rivets to mount these sockets.  Replaces Fender part number 0023606049.
Part #TS-9-700-6
$25.99
(for 6 sockets)


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  EXACT REPLACEMENT FOR MANY MAKES AND MODELS OF AMPS WITH HAND-WIRED TUBE SOCKETS.      Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.   For 3/4"  hole.  Bottom mounting (mounted from the inside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TR-144 or TR-146 tube retainers, or the TS-325S tube shield.
Part #TS-9-601
$2.49


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  EXACT REPLACEMENT FOR MANY MAKES AND MODELS OF AMPS WITH HAND-WIRED TUBE SOCKETS.      Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.   For 3/4"  hole.  Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TR-144 or TR-146 tube retainers, or the TS-325S tube shield.
Part #TS-9-610
$2.49



Click on photo for
larger view
Solid-State Tube Rectifier Replacement.
Replaces 5AR4, GZ34, 5U4, 5Y3 rectifier tubes.  Use when less "sag" is desired in the power supply.  1.31"  diameter, 0.89" tall (not including pins and center post).

Costs about 35% less than a new rectifier tube, and unlike tubes, should last indefinitely.    No deterioration over time.   Doesn't generate any heat, which lowers the heat given off by the amp.

NOTE! Because there is no warm up of a rectifier tube when using this solid state device, it is absolutely necessary that a standby switch is used in conjunction with this device.   Do not install in an amplifier that does not have a standby switch - always use the standby switch in amps so equipped when using the TSSR01.
Part #TSSR01

$14.95


Click on photo for
larger view
CUP WASHER, STAINLESS STEEL, SMALL, SET OF 4.  OD 3/8", ID 5/32".   Typically found on the back panel of some Fender™ Blonde/Brown era amps, and some Blackface vintage amps.   Set of 4 washers.   Fender™ part number 0037215049.  OUTSIDE EDGE OF WASHER IS BARELY LARGER THAN THE HEAD OF THE Fender™ BACK PANEL SCREWS.
Part #CW-401-4
$0.99
(for a set of 4 washers)



Click on photo for
larger view
CUP WASHER, STAINLESS STEEL, SMALL, SET OF 8.  OD 3/8", ID 5/32".   Typically found on the back panel of some Fender™ Blonde/Brown era amps, and some Blackface vintage amps.   Set of 8 washers.   Fender™ part number 0037215049.  OUTSIDE EDGE OF WASHER IS BARELY LARGER THAN THE HEAD OF THE Fender™ BACK PANEL SCREWS.
Part #CW-401-8
$1.79
(for a set of 8 washers)



Click on photo for
larger view
Ground Lug Terminals - Angled
Made from tin-plated brass - will not rust.   Used to connect a ground wire to a screw and nut on a chassis.  Angled, with two holes for soldering wires.   With built-in lock washer to keep the screw and nut from loosening.   Designed for a #8 size screw.   Pack of 5 terminals.

Part #GL-113
$1.39
(Pack of 5 terminals)





Click on photo for
larger view
TERMINAL STRIPS, 6 LUG, SET OF 2.   Perfect for amplifier circuit additions or modifications.   Center post for mounting to chassis.   All 6 terminals are isolated from ground.  Each terminal strip is 2-5/8 inches long.   The lugs are set on 3/8 inch centers.   Each lug will accept wires up to 16ga - smaller gauge allows multiple wires to be connected to each lug.   Set contains 2 terminal strips as pictured.   Mounting hardware not included.
Part #TS-825
$2.99
(for a set of 2 terminal strips)



Click on photo for
larger view
TERMINAL STRIPS, 7 LUG, SET OF 2.   Perfect for amplifier circuit additions or modifications.   End terminals on each strip are the mounting lugs, so they become a ground lug if attached to a metal chassis.   Each terminal strip is 2-5/8 inches long.   The lugs are set on 3/8 inch centers.   Each lug will accept wires up to 16ga - smaller gauge allows multiple wires to be connected to each lug.   Set contains 2 terminal strips as pictured.   Mounting hardware not included.
Part #TS-712
$3.69
(for a set of 2 terminal strips)


BLACK FENDER HANDLE
Click on photo for
larger view
ORIGINAL BLACK Fender™ GUITAR AMP HANDLE.  Black amplifier handle with vinyl sleeve over steel strap and one-screw mounting nickel-plated end caps.   Includes mounting hardware (two screws and T-nuts).  Introduced on Blonde, Brown, and Blackface™-era Fender™ amplifiers.  Used on 65 Twin Reverb™, 65 Deluxe Reverb™, 65 Super Reverb™, 65 Princeton Reverb™, 64 Vibroverb Custom, Custom Vibrolux™, Vibro-King™ 212 Enclosure, Blues Junior™, Pro Junior™, Acoustasonic™ Jr. DSP, Acoustasonic 30, Acoustasonic SFX II, Bassman™ 25, Bassman 60, Jazzmaster Ultralight™ Enclosure, Princeton 650™, Cyber Champ™, Rumble™ 112, Rumble 2x8, Super-Sonic™ 100 Head, Super-Sonic Twin, Super Champ™ X2/XD, and Bullet 15 DSP amplifier.  Fits most vintage and modern amplifiers.  7 3/4"  center to center screw placement.  9 1/4" handle length without end caps.   Original Fender™ part number 0990947000.
Part #FAH-332
$17.99


BROWN FENDER HANDLE
Click on photo for
larger view
ORIGINAL BROWN Fender™ GUITAR AMP HANDLE.  Brown amplifier handle with vinyl sleeve over steel strap and one-screw mounting nickel-plated end caps.   Includes mounting hardware (two screws and T-nuts).  Introduced on some Blonde and Brownface-era Fender™ amplifiers.  7 3/4"  center to center screw placement. 9 1/4" handle length without end caps.   Original Fender™ part number 0990944000.
Part #FAH-944
$16.99


Click on photo for
larger view
GUITAR AMP HANDLE - SIMILAR TO Fender™ HANDLEBlack handle strap, metal reinforced.  Nickel metal caps - may be used as replacement for vintage and reissue Fender™ amps.   Handle strap is 7/8" wide.   Designed for screw holes set 7 3/4 inches apart.   Looks similar to the original Fender™ part number 0990947000.   Screws and T-Nuts included.
Part #FAH-261
$8.49


Click on photo for
larger view

Fender™ VINTAGE HANDLE SCREWS
Pack of 2 stainless steel handle screws for Fender™ style FAH-332, FAH-261 handle.   1" Long, 10-32 threads.   Designed to work with a 10-32 T-Nut, in cabinet wood of 3/4" or less.    Will not work with external nut - must be a T-Nut.   Will not work with cabinet wood thicker than 3/4".  See Data Sheet here
Part #SC-403
$0.99
(for a pack of 2 screws)



Click on photo for
larger view

Fender™ EXTRA LONG VINTAGE HANDLE SCREWS
Pack of 2 stainless steel extra long handle screws for Fender™ style FAH-332, FAH-261 handle.   Used for vintage Fender™ style strap handles used on speaker cabinets, such as Bandmaster, Bassman, Showman, and Blonde or Blackface Tremolux.  1-1/4" Long, 10-32 threads.   Designed to work with a 10-32 T-Nut, in cabinet wood of 1-1/8" or less.    Will not work with external nut - must be a T-Nut.   Will not work with cabinet wood thicker than 1-1/8".  See Data Sheet here
Part #SC-403A
$0.99
(for a pack of 2 screws)




Click on photo for
larger view
Premium-quality steel T-nuts feature three razor-sharp teeth and 10-32 fine thread.  Works with all 10-32 screws - recommended for mounting many guitar amp handles.   Pack of 4 nuts.
Part TNUT-1032
99 cents
(pack of 4)




Click on photo for
larger view
Premium-quality steel T-nuts feature six razor-sharp teeth and extra-long barrels.  1/4"-20 coarse thread. The result is a T-nut that goes in straighter and holds tighter than ordinary T-nuts. As a bonus, the 6-prong design ensures that your T-nut will stay in place even when working at the edge of a driver hole. We guarantee that these are the finest T-nuts that you will find on the market. Recommended hole size is 1/4", thread is 10-32, barrel length is 11mm, or about 7/16".     Pack of 4 nuts.
Part 6-TNUT-1032
$1.59
(pack of 4)




Click on photo for
larger view
Fender™ VINTAGE STYLE GUITAR AMP HANDLE, RAISED, MEDIUM BROWN STITCHED SIMULATED LEATHER.
Medium brown simulated leather handle strap, replacement for Fender™ "tweed" style amps (as well as other vintage amps).  Has slight "raised" bump near the center of the handle.   Medium brown, white stitched.  5-7/8" from post position to post position, total length of strap when completely flat is 8-3/4".    Comes complete with two nickel-plated handle mounts and four screws.
Part #GAH-282
$17.95



Click on photo for
larger view
Fender™ or Ampeg™ VINTAGE STYLE GUITAR AMP HANDLE, RAISED, BLACK STITCHED SIMULATED LEATHER. Black raised handle strap, made of simulated leather, replacement for Fender™ "tweed" style amps or vintage Ampeg amps (as well as other vintage amps).  Has slight "raised" bump near the center of the handle.   Black, white stitched.  5-7/8" from post position to post position, total length of strap when completely flat is 8-3/4".   Mounts and screws are included.
Part #GAH-782
$17.95


Click on photo for
larger view
HANDLE MOUNTING KIT - FOR STRAP HANDLES    Complete set of hardware for mounting one leather style strap handle, including machine screws and T-Nuts.    Excellent for repairing strap handles where the old wood screws have pulled out of their holes.   Remove amp chassis, drill new holes with 3/16" or 5mm drill bit, tap in T-Nuts on the underside and mount the handle.    Fits Fender™ "tweed" style amps and some vintage Ampeg™ amps.   Works with our handles GAH-2, GAH-782.

Part #THH-2

$4.95


(Brown)

Click on photo for
larger view
Fender™ STYLE GUITAR AMP HANDLEBrown handle strap, "dogbone" style. Nickel end hooks - replacement for vintage and modern Fender™ amps.   Replacement for Fender™ part number 0990946000.   Does not contain Fender™ logo, so it may be used on other brands of amps.  Used on vintage and modern brownface and blonde tolex amps such as the 59 Bassman, Hot Rod Deluxe, Blues Deluxe, Blues Deville, Super-Sonic etc.   Color of handle strap is brown.   Screws not included - order screw SC-402 separately (takes a pack of 4 screws).
Part #FAH-328
$7.99


(Black)

Click on photo for
larger view
Fender™ STYLE GUITAR AMP HANDLEBlack handle strap, "dogbone" style. Nickel end hooks - replacement for vintage and modern Fender™ amps.  Replacement for Fender™ part number 0990943000.   Does not contain Fender™ logo, so it may be used on other brands of amps.  Used on vintage and modern black tolex amps such as the Hot Rod Deville, Blues Deluxe, Blues Deville, Super-Sonic, etc.   Color of handle strap is black.  Screws not included - order screw SC-402 separately (takes a pack of 4 screws).
Part #FAH-329
$7.99


Click on photo for
larger view

Fender™ "DOGBONE" HANDLE SCREWS
Pack of 4 nickel "Dogbone" handle screws for Fender™ style FAH-328 and FAH-329 handles.   Fits the handle on the Fender™ Hot Rod Deluxe, Hot Rod Deville, Blues Deluxe, and Blues Deville, as well as other Fender™ amps of similar design.  Also works with Hiwatt handles and other British design amp handles.   8-32 thread.
Part #SC-402
$1.59
(for a pack of 4 screws)




Click on photo for
larger view
Premium-quality steel T-nuts feature three razor-sharp teeth and 8-32 fine thread.  Works with all 8-32 screws - recommended for mounting many guitar amp handles.   Pack of 4 nuts.
Part TNUT-832
99 cents
(pack of 4)



Click on photo for
larger view
Fender™ AMP LOGO, FLAT BLACK. New original Fender™ reproduction, used in many recent and current model Fenders. "Flat" Fender™ logo, with black "tail", cast metal, mounting screws included.  Used on the upper left corner of the grill cloth on some recent and vintage era Fender™ amps.  Approx. 5 1/2" wide, the "F" in the logo is about 2 7/8" inches tall.   Original Fender™ part number 0994095000.
Part #FAL-916
$19.95
(each)



Click on photo for
larger view
Fender™ Nickel Chassis Straps - Large (5") for Twin, Bassman, Super, Showman, Vibro-King, Pro, Pro Reverb, Prosonic, etc.  Includes 2 straps, no screws or nuts.  Screw spacing is 5 inches center-to-center, strap length is 5 5/8" end-to-end.
Part #FCS-5-2
$7.95
(Two chassis straps, screws and nuts NOT included)




Click on photo for
larger view
Fender™ Nickel Chassis Straps - Medium (4") For Deluxe, Vibrolux, etc.   Includes 2 chassis straps, no screws or nuts.  Screw spacing is 4 inches center-to-center, strap length is 4 5/8" end-to-end.
Part #FCS-4-2
$7.49
(Two 4 in. chassis straps, screws and nuts NOT included)



Click on photo for
larger view
Fender™ Nickel Chassis Straps - Small (3")  For Champ, Music Master Bass, etc.  Includes 2 chassis straps, no screws or nuts.  Screw spacing is 3 inches center-to-center, strap length is 3 5/8" end-to-end.
Part #FCS-3-2
$6.99
(Two 3 in. chassis straps, screws and nuts NOT included)



Click on photo for
larger view
Fender™ Chassis Bolt and Nut Set - Works with all Fender Nickel or Revisit Chassis Straps for Brownface models.   Includes 4 bolts and 4 matching nuts with integral lock washers.   Fender™ part number 0022236049.
Part #FCB-4
$5.95
(
4 bolts, 4 nuts - complete set for one amp)



Click on photo for
larger view
KEPS NUT, ZINC, 8-32 THREAD, SET OF 4 NUTS.   Typically used on Fender™ Nickel Chassis Straps bolts, and for speaker mounting.   Works with all 8-32 screws.   Captive lock washer keeps nut tight.   Zinc coating retards oxidation.   Sold in a pack of 4.
Part NT-832-4
$0.69
(pack of 4 nuts)



ORIGINAL Fender™ THUMBSCREWS  Fender™ piggyback thumbscrews, holds head to cabinet on Showman, Bandmaster, Tremolux, Tone Master™ 212, Super-Sonic™ 212 and Super-Sonic 60 speaker enclosures and other head/cabinet sets. Heavy nickel plated steel, heavy knurling on knob. Set Of Two. Genuine Fender™ part number 0990720000.
Part #TS-251
$12.95
(Set of 2 Thumbscrews)




Click on photo for
larger view
BACK PANEL STAINLESS STEEL SCREWS (SET OF 4) FOR OPEN BACK CABINETS (such as Fender™ Blonde, Brown, Blackface and Silverface Series).     Set of 4 screws, stainless steel, 1 1/4 inches long, Phillips, oval head.  This set of four screws fits either the top or bottom rear panels on Fender™ combo amps from the 60s and 70s, and recent reissues of those BF and SF amps.   Use with either the CW-401 or CW-501 cup washers.
Part #SC-401-4
$0.99
(for a pack of 4 screws)




Click on photo for
larger view
BACK PANEL STAINLESS STEEL SCREWS (SET OF 8) FOR OPEN BACK CABINETS (such as Fender™ Blonde, Brown, Blackface and Silverface Series).     Set of 8 screws, stainless steel, 1 1/4 inches long, Phillips, oval head.   This set of eight screws fits both the top and bottom rear panels on Fender™ combo amps from the 60s and 70s, and recent reissues of those BF and SF amps.  Set of 8 completely replaces all of the screws on the two back panels.  Use with either the CW-401 or CW-501 cup washers.
Part #SC-401-8
$1.79
(for a pack of 8 screws)




Click on photo for
larger view
SATIN BLACK BACK PANEL STAINLESS STEEL SCREWS (SET OF 4)  FOR OPEN BACK CABINETS (such as Fender™ Blonde, Brown, Blackface and Silverface Series).     Set of 4 screws, satin black stainless steel, 1 1/4 inches long, Phillips, oval head.  This set of four screws fits either the top or bottom rear panels on Fender™ combo amps from the 60s and 70s, and recent reissues of those BF and SF May be used with the BCW-10 cup washers.   See data sheet
Part #SC-405-4
$0.99
(for a pack of 4 screws)




Click on photo for
larger view
SATIN BLACK BACK PANEL STAINLESS STEEL SCREWS (SET OF 8) FOR OPEN BACK CABINETS (such as Fender™ Blonde, Brown, Blackface and Silverface Series).     Set of 8 screws, satin black stainless steel, 1 1/4 inches long, Phillips, oval head.   This set of eight screws fits both the top and bottom rear panels on Fender™ combo amps from the 60s and 70s, and recent reissues of those BF and SF amps.  Set of 8 completely replaces all of the screws on the two back panels.  May be used with the BCW-10 cup washers.  See data sheet
Part #SC-405-8
$1.89
(for a pack of 8 screws)



Click on photo for
larger view
CUP WASHER, BLACK METAL, PACK OF 10.  Used with #8 Black screws, on amps and speaker cabinets.
Part #BCW-10
$1.69
(pack of 10)



Click on photo for
larger view

Fender™ Style Stainless Steel Corner Screws, Set of 8
Oval-head Phillips corner screws for counter-sunk amp corners, such as the FVC-2L and FVC-3 Fender™ corners.   3/4 inches long, Phillips head, stainless steel for long rust-free life.
Set of 8 screws, for four FVC-2L corners.

Part #SC-406-8

$2.99
(for a pack of 8 screws)



Click on photo for
larger view

Fender™ Style Stainless Steel Corner Screws, Set of 12
Oval-head Phillips corner screws for counter-sunk amp corners, such as the FVC-2L and FVC-3 Fender™ corners.   3/4 inches long, Phillips head, stainless steel for long rust-free life.
Set of 12 screws, for four FVC-3 corners.

Part #SC-406-12

$4.29
(for a pack of 12 screws)



Click on photo for
larger view

Fender™ VINTAGE HANDLE SCREWS
Pack of 2 stainless steel handle screws for Fender™ style FAH-332, FAH-261 handle.   1" Long, 10-32 threads.   Designed to work with a 10-32 T-Nut, in cabinet wood of 3/4" or less.    Will not work with external nut - must be a T-Nut.   Will not work with cabinet wood thicker than 3/4".  See Data Sheet here
Part #SC-403
$0.99
(for a pack of 2 screws)



Click on photo for
larger view

Fender™ EXTRA LONG VINTAGE HANDLE SCREWS
Pack of 2 stainless steel extra long handle screws for Fender™ style FAH-332, FAH-261 handle.   Used for vintage Fender™ style strap handles used on speaker cabinets, such as Bandmaster, Bassman, Showman, and Blonde or Blackface Tremolux.  1-1/4" Long, 10-32 threads.   Designed to work with a 10-32 T-Nut, in cabinet wood of 1-1/8" or less.    Will not work with external nut - must be a T-Nut.   Will not work with cabinet wood thicker than 1-1/8".  See Data Sheet here
Part #SC-403A
$0.99
(for a pack of 2 screws)



Click on photo for
larger view

Fender™ SELF-TAPPING SCREWS
Used in vintage Fender™ blackface and silverface amps for a variety of tasks.   Used to attach capacitor pans, tube sockets, transformers on smaller amps, chokes, etc.   Pack of 12 screws.  Replaces Fender™ part number 029913.
Part #SC-410-12
$3.50
(for a pack of 12 screws)




Click on photo for
larger view
FENDER SPEAKER MOUNTING SCREW WITH BOTH WOOD AND MACHINE THREADS, SET OF 12.   Locking nut and washer included.  Phillips head.   Drill hole, insert and tighten screws into wood from front of baffle.  Install grill cloth, and you have professional speaker mounting studs.   Replacement for original Fender™ speaker mounting studs.   Fender™ part number 0992094000.   Set of 12.
Part #SC-409-12
$12.95
(For a pack of 12 screws with nuts and lock washers)




Click on photo for
larger view
FENDER SPEAKER MOUNTING SCREW WITH BOTH WOOD AND MACHINE THREADS, SET OF 4.   Locking nut and washer included.  Phillips head.   Drill hole, insert and tighten screws into wood from front of baffle.  Install grill cloth, and you have professional speaker mounting studs.   Replacement for original Fender™ speaker mounting studs.   Fender™ part number 0992094000.   Set of 4.
Part #SC-409-4
$3.50
(For a pack of 4 screws with nuts and lock washers)



Click on photo for
larger view
ISOLATION WASHER - 3/8" - For #8 Screws

3/8" outside diameter neoprene bonded flat washer. Perfect for bolting speakers to cabinets. It will securely hold the speaker in place and stop any rattling. For use with #8 screws.  Ideal for vintage Fender amps with #8 speaker mounting screws.  Set of 4 washers.

Part #SIW-38-4

$0.59
(For a set of 4 washers)


Click on photo for
larger view
ISOLATION WASHER - 1/2" - For #10 Screws

Larger 1/2" outside diameter neoprene bonded flat washer. Perfect for bolting speakers to cabinets. It will securely hold the speaker in place and stop any rattling.  For use with #10 screws, such as a 10-32 machine screw.  Set of 4 washers.

Part #SIW-50-4

$0.69
(For a set of 4 washers)


Click on photo for
larger view

Vintage Fender™ Combo Style Style Blackface and Silverface 2-Leg Wrap-Around Cabinet Corner with Lip - Bright Nickel Plated Steel (Not designed for the Blackface or Silverface REISSUES.  NOT for vintage Fender™ Speaker Cabinets or Heads, such as Bassman, Bandmaster, Showman, etc.  These corners fit most vintage Fender combo amps.)   Recreation of the vintage Fender™ corners with counter-sunk screw holes.   Set of 4, includes screws.
Part #FVC-2L

$5.99
(Set of 4 corners with screws)



Click on photo for
larger view

Vintage Fender™ Style 2-Leg and 3-Leg Corners with counter-sunk screw holes.   Bright nickel-plated steel.   Recreation of the vintage style corners with counter-sunk screw holes from the 60s and 70s.  Two FVC-2L type corners with two legs and a lip, and two FVC-3 corners with three legs.  Typically used around the bottom of the Bassman Ten (or Bassman 10) Combo Amp from 1972 to 1982.  Set of 4 corners total - two FVC-2L for the front, and two FVC-3 for the back. Includes oval-head tapered stainless screws.
Part #FVC-23

$6.50
(Set of 4 corners with screws)



Click on photo for
larger view

Fender™ Style Stainless Steel Corner Screws, Set of 8
Oval-head Phillips corner screws for counter-sunk amp corners, such as the FVC-2L and FVC-3 Fender™ corners.   3/4 inches long, Phillips head, stainless steel for long rust-free life.
Set of 8 screws, for four FVC-2L corners.

Part #SC-406-8

$2.99
(for a pack of 8 screws)



Click on photo for
larger view

Fender™ Style Stainless Steel Corner Screws, Set of 12
Oval-head Phillips corner screws for counter-sunk amp corners, such as the FVC-2L and FVC-3 Fender™ corners.   3/4 inches long, Phillips head, stainless steel for long rust-free life.
Set of 12 screws, for four FVC-3 corners.

Part #SC-406-12

$4.29
(for a pack of 12 screws)



Click on photo for
larger view
Black Oval-Head Corner Screws, Set of 8
Black oval-head Phillips corner screws for counter-sunk amp corners.   Works with Vox black plastic corners, and Fender style black metal corners with recessed screw holes.   #6 x 3/4 inches long, Phillips head, black oxide.  Screws are beveled under the head for use in countersunk holes.   Length measured from the edge of the head to tip of the screw.
Set of 8 screws.
Part #SC-411-8
$1.50
(For a set of 8 black oval-head Phillips screws)


Click on photo for
larger view
Fender™ Style Pop-Out 2" Caster Wheels - Set of 4.    Great for Fender™ and many other brands of amps or cabinets.   Each wheel capable supporting 45 lbs, or 180 lbs total for the set of 4.   Wheels 2" in diameter.  The same type of removable caster wheels used on Fender™ amps since the 1960s.   Note:  Mounting screws NOT included.   Must drill 5/8" hole in bottom of cabinet to accommodate post for wheel.
Part #FCW-4R
$29.95
(Set of 4 pop-out casters)

NOT SOLD OUTSIDE the USA


Click on photo for
larger view
Fender™ Style Flat Mount 2" Caster Wheels - Set of 4.    Great for Fender™ and many other brands of amps or cabinets.   Each wheel capable of supporting 45 lbs, or 180 lbs total for the set of 4.   Wheels 2" in diameter.   Specifications found here.   Note:  Mounting screws NOT included.
Part #FCW-4F
$29.95
(Set of 4 casters)

NOT SOLD OUTSIDE the USA



Click on photo for
larger view
NICKEL GLIDE FEET, Revisit™, PACK OF 4, SCREWS INCLUDED.  Nickel cover over rubber foot.  15/16" Diameter, 0.33" Tall.   Replacement for glides used on many Fender™ amplifiers, including the blackface and silverface designs.  Set of 4, includes 7/8" wood screws.   Replaces Fender™ part number 0993900000.
Part #SG-239
$4.95
(pack of 4 with screws)


Click on photo for
larger view
GENUINE Fender™ SPHINX GLIDE FEET, PACK OF 4, SCREWS INCLUDED.
  • Set of four metal amplifier cabinet glide feet with rubber bushings and mounting screws.   1-1/4" diameter.  Fender™ part number 0993900000.
  • Fits Cyber-Champ™, Stage™ 100/112SE, Ultimate Chorus, Princeton 65 DSP/650, GE-112 Enclosure, Tone-Master™ Enclosures, Vibro-King™ 212 Enclosure, Pro Reverb, Deluxe 90 DSP/900, Acoustasonic™ 30/SFX II, Stage™ 1000/1600, Super-Sonic™ Series, Bassman™ Enclosures, Concert™, "The Twin", 65 Twin Custom™ 15, Steel King™, Hot Rod Deluxe™ Enclosures, Cyber Deluxe, and Cyber-Twin™ amplifiers.
  • Fits most vintage and modern Fender™ amplifiers, but is larger than the traditional 1" diameter glide on most blackface and silverface amps.

Part #SG-939

$12.99
(pack of 4 with screws)


Click on photo for
larger view

NICKEL GLIDE FEET, Fender™ STYLE, PACK OF 4, 3 PRONG HAMMER TYPE.
Older style 3-prong glide feet for Fender™ amplifiers - metal cap has 3 prongs, and the cap is hammered into the base of the amplifier.

Part #CG-068
$3.95
(pack of 4)


Click on photo for
larger view
LARGE SIZED STRAIN RELIEF FOR 35/64" X 5/8" HOLE
Popular strain relief found on most vintage guitar amplifiers with round power cords, including most vintage Fender™ amps.   Designed for 5/16" cord diameter (3 conductor 18ga power cable).   Click here for specific dimensions of chassis hole.   For a strain relief removal / installation tool to make the job much easier, see the YTH-205 below.
Part #SR-1200
$0.99


Click on photo for
larger view
STRAIN RELIEF INSTALLATION/REMOVAL TOOL
Removing and installing a strain relief can be a frustrating job.   Standard pliers just do not get the job done and can damage the strain relief.   These special strain relief pliers are just what you need.  They fit perfectly on the AC power cord strain relief and give you the leverage you need to compress the strain relief for easy removal and installation, without damage.
Part #YTH-205 - Note: Limited Quantity available at the moment.
$14.95


Click on photo for
larger view
SMALL RUBBER CHASSIS GROMMET FOR 3/8 INCH CHASSIS HOLE (GROMMET INNER HOLE 1/4 INCH)
Chassis grommet, for electrical insulation, wire protection and management, shock absorption, or mechanical isolation.    This grommet has a 1/4 inch diameter inner hole, and mounts in a 3/8 inch chassis hole.   Full datasheet here.
Part #RCG-739
$0.49
each


Click on photo for
larger view
LARGE RUBBER CHASSIS GROMMET FOR 1/2" CHASSIS HOLE (GROMMET INNER HOLE 3/8 INCH)
Chassis grommet, for electrical insulation, wire protection and management, shock absorption, or mechanical isolation.    This grommet has a 3/8 inch diameter inner hole, and mounts in a 1/2 inch chassis hole.   Full datasheet here.
Part #RCG-745
$0.49
each

Fender™ Capacitors


CAPACITOR, SILVER MICA, RADIAL
Rated at 500 volts, values from 10pF to 750pF. Radial leads.  Tolerance ±5%.  Dipped in epoxy coating.    (See Options)

1000pF = 1nF = 0.001uF

Part #C-SM-XX
Starting at
$0.80
Select Option:


Quantity:


CAPACITOR, POLYPROPYLENE, RADIAL.
  Similar to orange drop style, rated at 630 volts.  Values from 0.001uF to 0.47uF   Radial leads.  (See Options)


Part #C-PR-XX
Starting at
$0.30
Select Option:


Quantity:


CAPACITOR, METAL FILM, AXIAL -
Similar to Mallory 150 style, rated at 630 volts.   Values from 0.001uF to 0.47uF.  Axial Leads.   (See Options)

Part #C-MF-XX
Starting at
$0.90
Select Option:



Quantity:

  F&T Premium Capacitors

Click on photo for
larger view
CAPACITOR, F&T BRAND, AXIAL LEAD ELECTROLYTIC, VARIOUS VALUES AND VOLTAGES AVAILABLE (SEE OPTIONS)  Made in Germany. Founded in 1948 by Heinz Fischer and Alfred Tausche, F&T Capacitors has over 75 years of experience in producing some of the finest capacitors available today. F&T Caps are known for their great stability and reliability.  Values available include 10uF/500V, 16uF/475V, 22uF/500V, 30uF/500V, 47uF/500V, 80uF/450V, 100uF/100V, 100uF/450V, and 220uF/300V.  Choose capacitor value under the Select Option box.
Part #FT-CAP-XX
Starting at
$4.95
Select Option:


Quantity:

  Sprague Premium Cathode Bypass Axial Capacitors

Click on photo for
larger view
SPRAGUE AXIAL 25uf/50V  Replacement for the 25uF/25V axial cathode bypass capacitors commonly found in vintage Fender amps from the 1950s through the 1980s.  Sprague, founded in 1926, is considered one of the premier capacitor manufacturers in the world.

Part #SP-CAP-25-50

$4.95

  Tube Amp Doctor Premium Capacitors


Click on photo for
larger view
Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 8uF-475V

12mm diameter x 26mm Length
Rated
105° C for Long Life
8uF - 475 Volts DC
Common replacement in many vintage Fender Amps.


Part #TAD-CAP-8-475
$4.75
In stock



Click on photo for
larger view
Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 16uF-475V

12mm diameter x 30mm Length
Rated
105° C for Long Life
16uF - 475 Volts DC


Part #TAD-CAP-16-475
$4.95
In stock



Click on photo for
larger view

Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 22uF-500V

16mm diameter x 32mm Length
Rated
105° C for Long Life
22uF - 500 Volts DC


Part #TAD-CAP-22-500
$5.95
In stock



Click on photo for
larger view

Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 22uF-500V

16mm diameter x 32mm Length
Rated
105° C for Long Life
22uF - 500 Volts DC


Part #TAD-CAP-22-500
$5.95
In stock



Click on photo for
larger view

Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 100uF-350V

22mm diameter x 38mm Length
Rated
105° C for Long Life
100uF - 350 Volts DC


Part #TAD-CAP-100-350
$12.95
In stock



Click on photo for
larger view
Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor  220uF-350V

25mm diameter x 51mm Length
Rated
105° C for Long Life
220uF - 350 Volts DC


Part #TAD-CAP-220-350
$19.95
In stock



Click on photo for
larger view
Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 25uF-25V

6mm diameter x 14mm Length
Rated
105° C for Long Life
25uF - 25 Volts
Perfect replacement for axial cathode bypass capacitors in many Fender amps


Part #TAD-CAP-25-25
$1.75
In stock



Click on photo for
larger view
Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 5uF-50V

5mm diameter x 13mm Length
Rated
105° C for Long Life
5uF - 50 Volts
Perfect replacement for axial cathode bypass capacitors in the vibrato circuit of many Fender amps


Part #TAD-CAP-5-50
$3.50
In stock



Click on photo for
larger view

Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 47uF-500V

22mm diameter x 39mm Length
Rated
105° C for Long Life
47uF - 500 Volts DC


Part #TAD-CAP-47-500
$12.95
In stock



Click on photo for
larger view

Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 70uF-350V

18mm diameter x 40mm Length
Rated
105° C for Long Life
70uF - 350 Volts DC


Part #TAD-CAP-70-350
$8.95
In stock



Click on photo for
larger view

Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 100uF-350V

22mm diameter x 38mm Length
Rated
105° C for Long Life
100uF - 350 Volts DC


Part #TAD-CAP-100-350
$12.95
In stock



Click on photo for
larger view
Tube Amp Doctor™ Gold Cap Electrolytic Axial Capacitor 80uF-100V

9.5mm diameter x 21.5mm Length
Rated
105° C for Long Life
80uF - 100 Volts
Perfect replacement for bias supply
capacitors in many Fender amps


Part #TAD-CAP-80-100
$4.95
In stock

  Ruby Gold Premium Capacitors

Click on photo for
larger view
CAPACITOR, RUBY GOLD BRAND, AXIAL LEAD ELECTROLYTIC, 220uF-350V  Ruby Gold capacitors are used by many original amplifier manufacturers in Europe and the U.S.A.  Ruby Gold Capacitors are rated at 105° C for longer life, improved stability in the hot environment of tube amplifiers, and increased protection against electrolyte deterioration.   Ideal as replacement in vintage audio and guitar amplifiers.  220uF/350V.
Part #RG-CAP-220-350
$9.95

  MOD Axial Capacitors

Click on photo for
larger view
MOD CAPACITOR, AXIAL LEAD ELECTROLYTIC, VARIOUS VALUES AND VOLTAGES AVAILABLE (SEE OPTIONS)  Mod™ Electronics electrolytic capacitors offer long-lasting performance at the highest degree. These capacitors are designed with tube amplifiers in mind; each capacitor is rated at 105°C. This temperature rating provides a highly-stable capacitance in any device, be it vacuum tube or solid state. The Mod™ electrolytic capacitor line features capacitance values that are common in many vintage amplifiers.   Values available include 8uF/150V, 16uF/475V, 20uF/500V, 25uF/50V, 70uF/350V, 100uF/100V, and 100uF/350V.   Choose capacitor value under the Select Option box.
Part #MOD-CAP-XX
Starting at
$1.00
Select Option:


Quantity:

  Illinois Capacitor Electrolytic Capacitors

Click on photo for
larger view
CAPACITOR, ILLINOIS CAPACITOR BRAND, AXIAL LEAD ELECTROLYTIC, VARIOUS VALUES AND VOLTAGES AVAILABLE (SEE OPTIONS)  Illinois Capacitor Company was founded in 1934 in Chicago, IL, and over 80 years later continues to produce benchmark quality capacitors for industry.     Illinois Capacitor is now a subsidiary of Cornell Dubilier, another American capacitor manufacturer tracing its roots to 1909.  Values available include 2.2uF/50V, 4.7uF/50V, 10uF/160V, 10uF/450V, 22uF/50V, 22uF/500V, 33uF/450V, 47uF/63V, 47uF/500V, 80uF/450V, 100uF/25V, 100uF/35V 100uF/100V, 100uf/350V, 220uF/16V, 220uF/50V, 220uF/100V, 220uF/300V, 1000uF/35V, 1000uF/50V, 2200uF/50V and 5000uF/55V.  Choose capacitor value under the Select Option box.
Part #IC-CAP-XX
Starting at
$0.99
Select Option:


Quantity:

  Axial Electrolytic Capacitors - Other Brands

Click on photo for
larger view
CAPACITOR, AXIAL LEAD ELECTROLYTIC, VARIOUS VALUES AND VOLTAGES AVAILABLE (SEE OPTIONS)  Values available include the following:
25uF/25V 100uF/25V 220uF/25V 2200uF/25V
100uF/50V 0.68uF/50V 25uF/50V
  47uF/63V 70uF/100V 100uF/100V
  8uF/150V 10uF/160V 100uF/350V
220uF/350V 4.7uF/450V 8uF/450V 10uF/450V
  22uF/450V 33uF/450V 47uF/450V
16uF/475V 20uF/500V 20uF/600V 80uF/500V

Choose capacitor value under the Select Option box.
Part #EL-CAP-XX

Starting at
$1.00
Select Option:


Quantity:


Click on photo for
larger view
CAPACITOR, AXIAL LEAD ELECTROLYTIC, DJE.

80uF/500V.   Commonly used in Fender amps from 1962-present.  Rated 85 degrees C, -10%/+20% tolerance.

Part #EL-CAP-80/500

$4.95


Click on photo for
larger view


CAPACITOR, CE Manufacturing™ MULTI-SECTION CAN, 30uF/30uF/30uF @ 525V,  1 3/8" D X 3-1/2" H.  Made in USA on the original Mallory equipment.  Twist-lock tabs for mounting to chassis.    Replacement for Fender main filter capacitor on the Princeton 6G2, from 1960-1962.  Rated 85 degrees C, -10%/+50% tolerance, 1-3/8" diameter x 3-1/2" tall.
Part #C-EC-30X3-525

$56.99



Click on photo for
larger view
Fender™ Electrolytic Capacitor Kits
Fender capacitor kits contain all of the main filter, decoupling filter, bias filter and preamp cathode bypass electrolytic capacitors for most amps from the blackface and silverface eras.
Prices starting at $32.95 Click here to see the full selection of Fender capacitor kits.

Click on photo for
larger view
FUSE HOLDER, Fender™ STYLE, HIGH QUALITY USED WITH AGC TYPE FUSE
Fender™ style fuse holder, replacement for many other brands.   Twist-lock cap.   Durable, rugged design - better than OEM.  Fits "American" style AGC fuses (1/4" x 1 1/4").
Part #FH-201
$4.50


Click on photo for
larger view
FUSE HOLDER, MODERN TWEED Fender™ STYLE,  This fuse holder is similar to the fuse holders used on the Fender Tweed Series Amplifiers back in the late 1940s to the early 1960s. This fuse holder will serve as an excellent replacement for any Fender Tweed Amplifier in need of a repair. Amplifiers like the Fender Tweed Champ, Fender Tweed Princeton, Fender Tweed Deluxe, and so on. In the event your original fuse holder cap was lost or damaged, the cap on this fuse holder will fit on your original fuse holder.  Fits "American" style AGC fuses (1/4" x 1 1/4").
Part #FH-211
$4.95



Click on photo for
 larger view
Revisit™ F1 to F2 Faston Push-on Terminal Adapters
Used to change the size of speaker terminals from .187" (3/16") to .250" (1/4").  Also used to change some PC board connectors size.   Female .187" to male .250"
Part #F1F2
$1.89
(Set of 2 Adapters)




Click on photo for
 larger view
Revisit™ F2 to F1 Faston Push-on Terminal Adapters
Used to change the size of speaker terminals from .250" (1/4") to .187" (3/16").  Also used to change some PC board connectors' size.   Female .250" to male .187"
Part #F2F1
$1.89
(Set of 2 Adapters)




Click on photo for
 larger view
Revisit™ SPEAKER HARNESS
Replacement right-angle plug with 34" cable and 3/16" fast-on connectors.    Used to replace speaker cable in most combo amplifiers where the speakers are connected to the amplifier chassis via a 1/4" jack and plug.   18ga black zip cord, right-angle plug and fast-on connectors for attachment to one speaker.
Part #SCH-280 - NOTE: ONLY 1 LEFT IN STOCK!
$6.99


Click on photo for
 larger view

SPEAKER JUMPER CABLE
polyvinyl insulated silver plated copper speaker wire, 18 gauge, twisted pair, black and white.   Terminated at each end in standard 3/16" speaker fast-on connectors.   Great for connecting speakers in parallel in 2x12 or 4x12 cabinets.   24 inches (61 cm) long.   Made in USA.
Part #SJ-150

$5.99



BUILD YOUR OWN Speaker Harness for Combo Amps:

Choose the SJ-150 cable (above) along with the P-287 Plug (below).   Cut off the cable's fast-on connectors on ONE end of the cable.  Strip both conductors of cable back about 1/4" on that end.  Solder that end to the P-287 plug (black to the sleeve, white to the tip.).   This will give you a 24 inch speaker harness.   Note:  Cable-building experience strongly recommended.   Soldering equipment needed.

Total cost for materials will be $5.99 + $3.95 = $9.94.


Click on photo for
 larger view
PLUG, 1/4", MONO, RIGHT ANGLE, SOLDER TERMINALS, STRAIN RELIEF
Similar to the Switchcraft 226 right-angle plug.   Nickel plated copper alloy.   2-conductor right-angle phone plug, solder terminals.
Part #P-287
$3.95


Click on photo for
larger view
Fender™ STYLE SPEAKER CABINET JACK PLATE ASSEMBLY WITH JACK
As used on blackface and silverface speaker cabinet (Bassman, Bandmaster, Showman, etc).    Complete with long-bushing Switchcraft jack with nut and trim washer, and two
nickel jack ferrules for the inside and outside of the cabinet back.  For wood panels between 3/8 inch and 1/2 inch thick.   Keep your vintage Fender™ cabinet looking original!
Part #JPC-577
$16.95


Click on photo for
larger view
JACK PLATE, BLACK METAL, SINGLE 1/4" JACK, 2" OUTSIDE DIAMETER. Similar in style to vintage Fender™ jack plates.  Works well with the Switchcraft J-11 1/4" jacks that we carry. Hole is 3/8", for most Switchcraft type jacks.  Easy to install, economical.   Includes 3 black oxide coarse-thread mounting screws, #6x3/4".   Jack not included - order separately.   For size specifications, click here.
Part #JP-180
$1.89



Click on photo for
larger view
Revisit™ JACK PLATE COMPLETE WITH SWITCHCRAFT #11 JACK.  Switchcraft #11 jack preinstalled with lock washer and trim washer. Outside diameter 2 inches (51mm). Minor assembly required. Designed to fit flush against a 1 1/8" (29mm) cabinet hole. Easy to install - drill 1 1/8" hole in cabinet, attach speaker wiring to jack and speaker, attach plate to cabinet.
Part #JPC-180
$4.95


Click on photo for
 larger view

Fender™ Style RCA Plug from Switchcraft
This is the original Switchcraft RCA plug used on vintage Fender amps for footswitch and reverb in / out connections. For cable up to 0.125" (3.18mm) diameter.
Part #P-3501MX

$1.49



Fender™ Jacks
(Also see our complete line of jacks)




Click on photo for
larger view
Fender™ Input Jack Replacement Kit for one channel amplifiers (or for just one channel of a two-channel amp).    For vintage Fender™ amps made before 1980 from the original tweed, blonde, brown, blackface and silverface eras.  Contains two Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus two 68K and one 1 Meg carbon composition resistors.   This is the input circuit replacement kit for the following one-channel amplifiers:   Bronco AB764 (1967-1975), Champ AA764 (1964-1982, both blackface and silverface), Champ 5E1 (1955-1956), Champ 5F1 (1956-1964), Princeton (1963-1979), Princeton Reverb (1964-1981), VibroChamp AA764 (Blackface 1964-67, Silverface 1968-1982).   Note:   Does NOT work with the Fender Super Twin, 300PS, or Fender 75.
Part #FJK-1
$9.95



Click on photo for
larger view
Fender™ Input Jack Replacement Kit for two channel amplifiers.    For vintage Fender™ amps made before 1980 from the original tweed, blonde, brown, blackface and silverface eras.  Contains four Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus four 68K and two 1 Meg carbon composition resistors.   This is the input circuit replacement kit for the following two-channel amplifiers:   Bandmaster (1956-1975), Bandmaster Reverb (1968-1980), Bantam Bass (1969-1971), Bassman (1961-1982), Bassman 10 (Silverface 1972-1982), Concert (1959-1965 Brown and Blackface), Deluxe (1963-1966), Deluxe Reverb (1963-1982), Dual Showman (1967-69 Silverface), Dual Showman Reverb (1968-1981), Harvard 6G10 (1955-1962 Tweed), Pro (1960-1965 Brown and Blackface), Pro Reverb (1965-1982 Blackface and Silverface), Quad Reverb (1972-1979 Silverface) Showman (1960-1967 Blonde and Blackface), Showman (1968-1970 Silverface), Super (1960-1963 Brown), Super Reverb (1963-1981 Blackface and Silverface), Super Six Reverb (1972-1979), Tremolux (1955-1966 Tweed, Blonde and Blackface), Twin (1958-1963 Tweed and Blonde), Twin Reverb (1963-1982 Blackface and Silverface), Vibrosonic (1959-1963 Brown), Vibrolux (1961-1964 Brown and Blackface), Vibrolux Reverb (1964-1982 Blackface and Silverface), Vibrosonic (1972-1981 Silverface), Vibroverb (1963-1964 Brown and Blackface).
Part #FJK-2
$19.95




Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, Switchcraft
Found in many guitars, effects pedals, amps speaker output.  Includes nut and washer.
Part #J-11
$3.79


Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, Switchcraft, LONG BUSHING
Same as the J-11 jack, but with longer (3/8") threaded bushing for mounting in thicker panels.  Includes nut and washer.
Part #J-L11
$4.79


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT (SHORTING), WIRED, Switchcraft
Found in vintage Fender
(and other) amps as the input jack.   Also used in the Hot Rod Deluxe/Deville, Blues Deluxe/Deville as the main speaker out jack.  Includes nut and washer.    Fender™ part number 0021550000 (originally 021550).   Peavey part number 71466004.
Part #J-12A
$4.79


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT (SHORTING), WIRED, Switchcraft, LONG BUSHING
Same as the J-12A jack, but with longer (3/8") threaded bushing for mounting in thicker panels.  Includes nut and washer.
Part #J-L12A
$5.50


Click on photo for
larger view
JACK, 1/4", TIP-RING-SLEEVE, OPEN CIRCUIT, WIRED, Switchcraft
Used with T/R/S plugs for either balanced connections or stereo connections.   Also very common in guitars with active pickups, and as the input jack on some effects pedals.   The ring conductor is used in these cases to "turn on" the battery by tying one leg of the battery to ground via the plug.  Fender part number 0013043000.
Part #J-12B
$4.35


Click on photo for
larger view
JACK, 1/4", TIP-SLEEVE, WITH ISOLATED SWITCHING.  Switchcraft
Used with for special switching applications - the two conductors for the switch are completely isolated from both the "hot" audio signal and the ground connection.   Used in some vintage amplifiers, including some early Fender™ models.   Isolated switch is normally open - closes when a plug is inserted.
Part #J-13
$10.50


Click on photo for
larger view
JACK, 1/4", TIP-SLEEVE, WITH TRANSFER SWITCHING.  Switchcraft 13A Jack.
Used with for special switching applications - the tip contacts one terminal when no plug is inserted, and contacts a different terminal with the plug in place.   Used in
a number of Fender™ models, both vintage and modern as the extension speaker jack (ex: Blues and Hot Rod Deluxe and Deville models).  Original Fender™ part number 0041701000 (originally 042701).   Also found in some Peavey amps, such as the Classic 50 speaker jack.
Part #J-13A
$9.95


Click on photo for
larger view
JACK, 1/4", TIP/RING/SLEEVE, WITH TIP SHUNT.  Switchcraft 13B Jack.
Tip/Ring/Sleeve Switchcraft jack.   Tip has a shunt contact, ring contact is open circuit.

Part #J-13B
$9.95


Click on photo for
larger view
Fender™ STYLE SPEAKER CABINET JACK PLATE ASSEMBLY WITH JACK
As used on blackface and silverface speaker cabinet (Bassman, Bandmaster, Showman, etc).    Complete with long-bushing Switchcraft jack with nut and trim washer, and two
nickel jack ferrules for the inside and outside of the cabinet back.  For wood panels between 3/8 inch and 1/2 inch thick.   Keep your vintage Fender™ cabinet looking original!
Part #JPC-577
$16.95


Click on photo for
larger view
RCA JACK, PANEL MOUNT
Exact
replacement for the reverb tank and footswitch jacks on the rear panel of Fender™ brownface amplifiers. Also may be used as an alternative RCA jack replacement for the RCA speaker jacks used on some Fender™ Tweed models from the 1950s.   Made by Switchcraft.
Part #J-122
(Also see our complete line of jacks)
$2.99

  Fender™ Input Jack Replacement Kits for Vintage Blonde, Brown Amps (1959-1963)


Click on photo for
larger view
Fender™ Input Jack Replacement Kit for one channel amplifiers (or for just one channel of a two-channel amp).    For vintage Fender™ amps made before 1980 from the original tweed, blonde, brown, blackface and silverface eras.  Contains two Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus two 68K and one 1 Meg carbon composition resistors.   This is the input circuit replacement kit for the following one-channel amplifiers:   Bronco AB764 (1967-1975), Champ AA764 (1964-1982, both blackface and silverface), Champ 5E1 (1955-1956), Champ 5F1 (1956-1964), Princeton (1963-1979), Princeton Reverb (1964-1981), VibroChamp AA764 (Blackface 1964-67, Silverface 1968-1982).   Note:   Does NOT work with the Fender Super Twin, 300PS, or Fender 75.
Part #FJK-1
$9.95



Click on photo for
larger view
Fender™ Input Jack Replacement Kit for two channel amplifiers.    For vintage Fender™ amps made before 1980 from the original tweed, blonde, brown, blackface and silverface eras.  Contains four Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus four 68K and two 1 Meg carbon composition resistors.   This is the input circuit replacement kit for the following two-channel amplifiers:   Bandmaster (1956-1975), Bandmaster Reverb (1968-1980), Bantam Bass (1969-1971), Bassman (1961-1982), Bassman 10 (Silverface 1972-1982), Concert (1959-1965 Brown and Blackface), Deluxe (1963-1966), Deluxe Reverb (1963-1982), Dual Showman (1967-69 Silverface), Dual Showman Reverb (1968-1981), Harvard 6G10 (1955-1962 Tweed), Pro (1960-1965 Brown and Blackface), Pro Reverb (1965-1982 Blackface and Silverface), Quad Reverb (1972-1979 Silverface) Showman (1960-1967 Blonde and Blackface), Showman (1968-1970 Silverface), Super (1960-1963 Brown), Super Reverb (1963-1981 Blackface and Silverface), Super Six Reverb (1972-1979), Tremolux (1955-1966 Tweed, Blonde and Blackface), Twin (1958-1963 Tweed and Blonde), Twin Reverb (1963-1982 Blackface and Silverface), Vibrosonic (1959-1963 Brown), Vibrolux (1961-1964 Brown and Blackface), Vibrolux Reverb (1964-1982 Blackface and Silverface), Vibrosonic (1972-1981 Silverface), Vibroverb (1963-1964 Brown and Blackface).
Part #FJK-2
$19.95




Click on photo for
larger view
SAVE WITH MULTIPACK!  JNUT-38 JACK NUT AND WASHER, METAL, SWITCHCRAFT, SET OF 6
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.   Set of 6 washers and 6 nuts.
Part #JNUT-38-6
$4.50
(Set of 6 washers and 6 nuts)


JACK NUT AND WASHER, METAL, SWITCHCRAFT
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.
Part #JNUT-38
$0.89
(Set of 1 washer and 1 nut)



Click on photo for
larger view
JACK LOCK WASHER, METAL
Replacement lock washer for all Alpha pots with 3/8" bushing and Mesa Boogie pots, as well as Switchcraft 1/4" jacks.
Part #W-38
$0.49

Fender™ Jewels



RED

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa/Boogie™, many others.   RED - the standard on Fenders since the 1940's.   Replaces Fender™ part number 0990952000.

Part #JL-115R
$2.99


AQUA

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa Boogie™, many others.   AQUA - the latest addition to jewel colors!   Aqua is a greenish blue, similar to cyan or light turquoise.  Replaces Fender™ part number 0990949000.   *Does not fit the Fender SuperChamp X2 or XD, Steel King, Stage 100 DSP, Stage 160 DSP, Princeton 65 DSP, Jazzmaster Ultralight, Deluxe 90 DSP, Cyber-Champ, Champion 30 DSP, SFX Satellite, Blues Junior series, Pro Junior, Princeton Chorus DSP, or similar models.


Part #JL-115Q
$4.65


VIOLET

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa Boogie™, many others.  Violet - just plain cool!

NOTE:  When illuminated by the bulb, this violet jewel tends to have a hue slanted toward the red spectrum, so some call the look a reddish-pinkish-violet color.   If you like violet/purple and want it toward the warmer end of the color spectrum, this is the jewel for you.   If you like it more bluish - toward the cooler end of the violet color zone, choose the purple jewel JL-115P below instead.

Part #JL-115V

$2.99


PURPLE

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa/Boogie™, many others.  Purple - just plain cool!   Replaces Fender™ part number 0990953000.   *Does not fit the Fender SuperChamp X2 or XD, Steel King, Stage 100 DSP, Stage 160 DSP, Princeton 65 DSP, Jazzmaster Ultralight, Deluxe 90 DSP, Cyber-Champ, Champion 30 DSP, SFX Satellite, Blues Junior series, Pro Junior, Princeton Chorus DSP, or similar models.

NOTE:  To the naked eye, this jewel looks blue until you put it in front of the P-47 bulb.   The bulb has an amber tint to it, so the combo makes the jewel glow purple.  When illuminated by the bulb, this purple jewel tends to have a hue slanted toward the blue spectrum, so some call the look a bluish-purple color.   If you like violet/purple and want it toward the cooler end of the color spectrum, this is the jewel for you.   If you like it more reddish - toward the warmer end of the violet color zone, choose the violet jewel JL-115V above instead. IMPORTANT: NOT RECOMMENDED FOR USE WITH THE LED-47 ... WILL LOOK DEEP BLUE INSTEAD OF PURPLE.

Part #JL-115P

$4.65


BLUE

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa Boogie™, many others.  Blue, for the California vibe.   Replaces Fender™ part number 0990959000.

NOTE:  Due to the orange glow of the bulb normally used behind this jewel, the resulting color is not a pure brilliant blue ... head on, it looks like a somewhat washed-out blue, and from a side angle, it looks more like purple.   This is not the fault of the jewel, but rather the combination of the blue color of the jewel combined with the orange glow of the bulb.  If used with a pure white light (such as a white LED), the resulting look is a deep blue color.

Part #JL-115B

$2.99


AMBER

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa Boogie™, many others.  Amber - jazzy look!   Replaces Fender™ part number 0990950000.
Part #JL-115A
$2.99


GREEN

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa Boogie™, many others.  Green - Texas style!  Replaces Fender™ part number 0990951000.

Part #JL-115G
$2.99


CLEAR

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa Boogie™, many others.  Clear, for the brightest light output.

Part #JL-115C
$2.99


WHITE

Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL, Fender™, Peavey™, Mesa/Boogie™, many others.  WHITE.

Part #JL-115W
$4.65



Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL KIT, Fender™, Peavey™, Mesa/Boogie™ , many others.   Kit of 6 jewels - change your light color as often as you like.   Contains one each red, amber, green, blue, violet and clear.
Part #JLK-115
$14.99



Click on photo for
 larger view
PILOT LAMP HOLDER, REPLACEMENT FOR FENDER, MESA BOOGIE, ORANGE, ETC.
Pilot lamp holder, fits 11/16" Chassis Hole
Bezel inner diameter: 0.570" Bezel inner diameter (including threading): 0.527"    Works with a standard bayonet lamp such as the 6.3V #47 lamp, or the LED-47.   Accepts all of the colored jewels on this page.

Part #LH-124
$5.50


RED

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, RED, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, red jewel and your choice of #47 bulb or equivalent LED-47.  The LED option provides a cooler, yet brighter light with much longer life.  LED color is `warm white`, for a color very close to that of a bulb.   Fits 11/16" chassis hole.   Designed for 6 volts (filament voltage in tube amps).  Ready for installation and wiring.

Available with 6V `warm white` LED or standard 6V incandescent bulb - choose in "Options"

Part #FLA-124R

Starting at
$8.50
Select Option:




BLUE

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, BLUE, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, blue jewel and your choice of #47 bulb or equivalent LED-47.  The LED option provides a cooler, yet brighter light with much longer life.  LED color is `warm white`, for a color very close to that of a bulb.   Fits 11/16" chassis hole.   Designed for 6 volts (filament voltage in tube amps).  Ready for installation and wiring.

Available with 6V `warm white` LED or standard 6V incandescent bulb - choose in "Options"

Part #FLA-124B

Starting at
$8.50
Select Option:




AMBER

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, AMBER, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, amber jewel and your choice of #47 bulb or equivalent LED-47.  The LED option provides a cooler, yet brighter light with much longer life.  LED color is `warm white`, for a color very close to that of a bulb.   Fits 11/16" chassis hole.   Designed for 6 volts (filament voltage in tube amps).  Ready for installation and wiring.

Available with 6V `warm white` LED or standard 6V incandescent bulb - choose in "Options"

Part #FLA-124A

Starting at
$8.50
Select Option:




CLEAR

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, CLEAR, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, clear jewel and your choice of #47 bulb or equivalent LED-47.  The LED option provides a cooler, yet brighter light with much longer life.  LED color is `warm white`, for a color very close to that of a bulb.   Fits 11/16" chassis hole.   Designed for 6 volts (filament voltage in tube amps).  Ready for installation and wiring.

Available with 6V `warm white` LED or standard 6V incandescent bulb - choose in "Options"

Part #FLA-124C

Starting at
$8.50
Select Option:




GREEN

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, GREEN, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, green jewel and your choice of #47 bulb or equivalent LED-47.  The LED option provides a cooler, yet brighter light with much longer life.  LED color is `warm white`, for a color very close to that of a bulb.   Fits 11/16" chassis hole.   Designed for 6 volts (filament voltage in tube amps).  Ready for installation and wiring.

Available with 6V `warm white` LED or standard 6V incandescent bulb - choose in "Options"

Part #FLA-124G

Starting at
$8.50
Select Option:




VIOLET

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, VIOLET, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, violet jewel and your choice of #47 bulb or equivalent LED-47.  The LED option provides a cooler, yet brighter light with much longer life.  LED color is `warm white`, for a color very close to that of a bulb.   Fits 11/16" chassis hole.   Designed for 6 volts (filament voltage in tube amps).  Ready for installation and wiring.

Available with 6V `warm white` LED or standard 6V incandescent bulb - choose in "Options"

Part #FLA-124V

Starting at
$8.50
Select Option:




WHITE

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, WHITE, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, white jewel and your choice of #47 bulb or equivalent LED-47.  The LED option provides a cooler, yet brighter light with much longer life.  LED color is `warm white`, for a color very close to that of a bulb.   Fits 11/16" chassis hole.   Designed for 6 volts (filament voltage in tube amps).  Ready for installation and wiring.

Available with 6V `warm white` LED or standard 6V incandescent bulb - choose in "Options"

Part #FLA-124W

Starting at
$9.50
Select Option:




PURPLE

Click on photo for
 larger view
PILOT LAMP ASSEMBLY, PURPLE, REPLACEMENT FOR FENDER
Complete pilot lamp assembly:  Includes pilot lamp holder, purple jewel and #47 bulb complete, fits 11/16" chassis hole.   Designed for 6.3 volts. Ready for installation and wiring.

The purple color on this lamp jewel is toward the cool end of the purple/violet range - so it has more of a bluish tint to the purple color.  In fact, the lamp jewel cover looks blue if the light is not turned on.  If you prefer a warmer tone (toward the red/pink end of the scale), choose the FLA-124V violet lamp assembly.  Not available with the LED option, as the color when using an LED is a deep blue rather than purple.
Part #FLA-124P

$9.50

Fender™ Knobs
(Also see our complete line of knobs)



Click on photo for
larger view
KNOB, Fender™ Style, Vintage Cream
Replaces Fender™ part number 0990933000.  "Fender™ Barrel" knob, cream white with brass inset and set-screw as used by
Fender™ blonde series amps.

Part #K-315
$2.95


Click on photo for
larger view
KNOB, Fender™ Style, Vintage Cream, Set of 6
Replaces Fender™ part number 0990933000.  "Fender™ Barrel" knob, cream white with brass inset and set-screw as used by:
Fender™ 1960-1964 for the Fender™ Bassman, Showman and Bandmaster Amp, and for several Fender™ Custom Shop and Fender™ Reissue amps:  Tone Master, Custom Vibrolux Reverb, Vibroking, Super Sonic Amp (blonde) etc.  Set of 6 knobs.

Part #K-315-6
$16.95
(for pack of 6 knobs)



Click on photo for
larger view
KNOB, Fender™ Style, Vintage Brown
Fender™ style amp knob, brown color with white pointer.   Used on Fender™ "Brownface" series amps from 1961 through 1963.   Knob is secured by set-screw, designed to fit a 1/4" shaft.  Includes internal brass inset.  Replaces Fender™ part number 0990934000, these knobs were used by Fender™ in the early 1960s for the Brown-Tolex Amps (Princeton 6G2, Deluxe 6G3, Super 6G4, Pro 6G5, Tremolux 6G9, Vibrolux 6G11, Concert 6G12, Reverb Unit 6G15, Vibroverb 6G16), and others Also very similar to the knob used on the Mesa-Boogie Maverick Dual Rectifier model - Mesa Boogie part number 408020.
Part #K-316
$2.95


Click on photo for
larger view
KNOB, Fender™ Style, Vintage Brown, Set of 6
Fender™ style amp knob, brown color with white pointer.   Used on Fender™ "Brownface" series amps from 1961 through 1963.   Knob is secured by set-screw, designed to fit a 1/4" shaft.  Includes internal brass inset.  Replaces Fender™ part number 0990934000, these knobs were used by Fender™ in the early 1960s for the Brown-Tolex Amps (Princeton 6G2, Deluxe 6G3, Super 6G4, Pro 6G5, Tremolux 6G9, Vibrolux 6G11, Concert 6G12, Reverb Unit 6G15, Vibroverb 6G16), and others Also very similar to the knob used on the Mesa-Boogie Maverick Dual Rectifier model - Mesa Boogie part number 408020.  Set of 6 knobs.
Part #K-316-6
$16.95
(for pack of 6 knobs)

Fender™ Lamps
(Also see our complete line of lamps)



Click on photo for
larger view
INDICATOR LAMP, #47, T-3-1/4, 6.3V, .15 AMP, BAYONET BASE
P-47
Long life general replacement lamps for dials, indicators, etc. Sold individually.  Replacement for Fender™   Replaces Fender™ part number 0021642049
Part #P-47
$0.99


Pots for Blonde and Brown Series Amps from
1960-1963
(Not Reissues)
Fender amps from 1960-1963 underwent many design changes, as Leo Fender was in a period of experimentation to achieve the ultimate Fender sound, so it is very difficult to assemble accurate Potentiometer Kits.   We do offer these individual pots which cover most of the needs of the "brownface" era.    For the model number and version, look on the tube chart in the back of the amp.


Click on photo for
larger view
POT - Revisit™, 24MM, SOLID SHAFT
24 mm carbon composition, 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 3/8" diameter bushing, solder lugs. For hand-wired American made amplifiers such as vintage Fender™ and others.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-XX
Starting at
$2.95
Select Option:

Quantity:



Click on photo for
larger view
POT - Revisit™, 24MM, SOLID SHAFT, 3M & 10M REVERSE AUDIO
24 mm carbon composition, 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 8mm diameter bushing, solder lugs. For hand-wired American made amplifiers such as vintage Fender™ and others.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-XX
Starting at
$3.95
Select Option:

Quantity:



Click on photo for
larger view
POT -  Revisit™ , 350K AUDIO WITH 70K TAP, 9MM BUSHING, FENDER™ BROWNFACE SERIES TREBLE POT
16mm carbon composition. 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 9mm" bushing, solder lugs. Special manufacture, to replace the treble pots on certain Fender™ 1961-1963 Brownface models, such as Bassman 6G6, Concert 6G12A, Pro 6G5A, Showman 6G14, Super 6G4A, Tremolux 6G9, Vibrolux 6G11, and the Vibroverb 6G16.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-350KA-70KT
$4.95

Fender™ Power Cords



Click on photo for
larger view
SUPER-LONG, 16 gauge Revisit™ 15 ft POWER CORD, 3-WIRE, SJT type,    OUR LONGEST POWER CORD!  Cut ends for installing (soldered connection) into many vintage amps using a 3-wire cord (or for upgrading 2 wire cords in older amps).    Cord length is a super-long 15 feet, cord thickness is 0.31 inches (about 5/16" or 7.9mm).  Standard NEMA 5-15P plug for North American use at 110-120 Volts AC ,rated at 13 amps maximum.  Used only in North America.
Part #PC-163SJT15
$19.95


Click on photo for
larger view
EXTRA-LONG 12 ft POWER CORD, 3-WIRE, 18ga, 10 Amps, SJT type.   Cut ends for installing (soldered connection) into many vintage amps using a 3-wire cord (or for upgrading 2 wire cords in older amps).    Cord length is an extra-long 12 feet, cord thickness is 0.29 inches (about 9/32"" or 7.3mm).   Wire gauge is 18AWG, rated at 10 amps.  This cord is of appropriate gauge and physical thickness for application in most medium to large guitar amps with "hard-wired" power cords (Fender, for example).    Standard NEMA 5-15 plug for North American use at 110-120 Volts AC, 13 Amps Max. Used only in North America.
Part #PC-183SJT12
$13.95


Click on photo for
larger view
8 ft POWER CORD, 3-WIRE, 18ga, SJT type.   Cut ends for installing (soldered connection) into many vintage amps using a 3-wire cord (or for upgrading 2 wire cords in older amps).    Cord length 8 feet, 18 gauge, cord thickness is 0.29 inches (about 9/32" or 7.3mm).   This cord is of appropriate gauge and physical thickness for application in most medium to large guitar amps with "hard-wired" power cords (Fender, for example).    Standard NEMA 5-15 plug for North American use at 110-120 Volts AC. Used only in North America.
Part #PC-183SJT8
$9.95


Click on photo for
larger view
8 ft POWER CORD, 3-WIRE, 18ga, SVT type, "Thin Line".   Cut ends for installing (soldered connection) into many vintage amps using a 3-wire cord (or for upgrading 2 wire cords in older amps).    Cord length 8 feet, 18 gauge, cord thickness is 0.24 inches (about 1/4" or 6.1mm).   Thinner than the PC-183SJT8 cord, this cord is better suited for replacing amp cords in smaller amplifiers where there was formerly a 2-wire cord without ground.  Standard NEMA 5-15 plug for North American use at 110-120 Volts AC. Used only in North America.
Part #PC-183SVT8-TL
$9.95


Click on photo for
larger view
15 ft EXTENSION CORD, 3-WIRE, 16ga, 13 Amps.   Quality extension cord for use on stage, at home, office or workshop.  Cord length is 15 feet, 16 gauge, 3-wire cord thickness is 0.31 inches (about 5/16" or 7.9mm).   Standard NEMA 5-15P plug and NEMA 5-15R single receptacle for North American use at 110-120 Volts AC, 13 amps maximum. Used only in North America.
Part #EC-5301
$19.95


Click on photo for
larger view
Fender™ style reverb or AC cable clamp.   Used on Fender amps since the early 60s to hold the reverb cable to the side of the cabinet.   Clamp is 3/8" diameter, comes with 3/4" screw for mounting.  Also used in some amplifiers to hold the AC cord to the cabinet wall.  Fender part number 022941.   Works on many other brands of amplifiers as well.
Part #
RCC-381
$0.99

Fender™ Reverb Tanks




Click on photo for larger view

Revisit™ Reverb Tank, 17" long, 2 spring, equivalent to Accutronics 4AB3C1B.   Input impedance 8 ohms, output impedance 2250 ohms, long decay (2.75 - 4.0 seconds), input insulated/output grounded, designed for horizontal mounting, open side down.   Primarily used by all Fender™ amplifiers with tube reverb from 1963-1990.   Also used in Reissue models like:   Fender™ Princeton Reverb, Fender™ Deluxe Reverb, Fender™ Vibrolux Reverb, Fender™ Pro Reverb, Fender™ Super Reverb , Fender™ Twin Reverb, Fender™ Quad Reverb , Fender™ Super Six Reverb, Fender™ Vibrosonic , Fender®`63 Reverb Unit Reissue, Fender®`65 Princeton Reverb Reissue
Fender®`65 Deluxe Reverb Reissue, Fender®`65 Super Reverb Reissue, Fender®`65 Twin Reverb Reissue , Fender™65 Twin Custom(TM) 15, Fender™ Concert II.
Also used in Mesa Boogie™, LAB Series, L5, L7, L9 and Koch™ Powertone I.  See explanation of Accutronics reverb tank numbering system here.  See a chart which lists AC impedance and DC resistance measurements for reverb tanks here

Replaces original Fender™ part number 0064063000.

Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.

View the 2-year warranty details here.
Part #4AB3C1B

"Bringing back the sound of vintage Accutronics tanks"

$43.79



Click on photo for larger view

Accutronics Reverb Tank, 17" long, 2 spring, 4AB3C1B current production.

Accutronics reverb tanks are a cheaply produced copy of the Belton tank, and are now made by Belton in South Korea.   They are of much lower quality than the original Accutronics reverb tanks made in Cary, Illinois until 2009.

Input impedance 8 ohms, output impedance 2250 ohms, long decay (2.75 - 4.0 seconds), input insulated/output grounded, designed for horizontal mounting, open side down.   Primarily used by all Fender™ amplifiers with tube reverb from 1963-1990.   Also used in Reissue models like:   Fender™ Princeton Reverb, Fender™ Deluxe Reverb, Fender™ Vibrolux Reverb, Fender™ Pro Reverb, Fender™ Super Reverb , Fender™ Twin Reverb, Fender™ Quad Reverb , Fender™ Super Six Reverb, Fender™ Vibrosonic , Fender®`63 Reverb Unit Reissue, Fender®`65 Princeton Reverb Reissue, Fender®`65 Deluxe Reverb Reissue, Fender®`65 Super Reverb Reissue, Fender®`65 Twin Reverb Reissue, Fender™ 65 Twin Custom(TM) 15, Fender™ Concert II, Fender™ Dual Professional.  Also used in Mesa Boogie™ MK2C and others, LAB Series L5, L7, L9, Koch™ Powertone I, Ampeg™ VT-40, Ampeg™ Super Rocket SR212 and B-52 AT-100.  See explanation of Accutronics reverb tank numbering system here.  See a chart which lists AC impedance and DC resistance measurements for reverb tanks here.

Accutronics products are made in South Korea.

Part #ACC-4AB3C1B

$39.99



Click on photo for larger view

Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics 9AB3C1B.   Input impedance 10 ohms, output impedance 2575 ohms, long decay (2.75 - 4 seconds), input insulated/output grounded, designed for horizontal mounting, open side down.   Common replacement for Fender.   Upgrade for the 4AB3C1B 2-spring tank.   See explanation of Accutronics reverb tank numbering system here.  See a chart which lists AC impedance and DC resistance measurements for reverb tanks here.

Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.

View the 2-year warranty details here.
Part #9AB3C1B

"Bringing back the sound of vintage Accutronics tanks"

$48.99



Click on photo for
larger view
Rubber mounting grommets for reverb tanks, package of four.   Provides shock absorption for tanks mounted directly to the inside of a wooden amp cabinet.  Mounting Hole Diameter = 3/8"  Outer Diameter = 1/2"
Part #RRG-4
$1.99
(For a pack of 4 grommets)



Click on photo for
larger view
Fender™ style reverb or AC cable clamp.   Used on Fender amps since the early 60s to hold the reverb cable to the side of the cabinet.   Clamp is 3/8" diameter, comes with 3/4" screw for mounting.  Also used in some amplifiers to hold the AC cord to the cabinet wall.  Fender part number 022941.   Works on many other brands of amplifiers as well.
Part #
RCC-381
$0.99


Click on photo for
larger view

Reverb Tank Bag for 17" tanks.   Used in a variety of amps, including Fender™ amps.  Works with any long (17") reverb tank.   Mounting screws not included.  Reverb bags give the reverb tank better isolation which results is fuller, richer reverb and less feedback.
Part #RB-017
$18.90
In Stock


Fender™ Switches
(Also see our complete line of switches)




Click on photo for
larger view

Fender™ STYLE VINTAGE FOOTSWITCH - NICKEL PLATED
Fender™ style vintage two-button footswitch found on 60s and 70s blackface and silverface amps with vibrato and reverb.  Sturdy
nickel metal construction.    Dual RCA Plugs, 12 ft cable, cable enters rear of pedal.   Replaces Fender™ part # 0994051000
Part #FBS-241
$48.95


Click on photo for
larger view

PREMIUM Fender™ STYLE FOOTSWITCH - BLACK
This is the highest quality reproduction of the iconic Fender Style 2-Button Footswitch on the market. Our Premium 2-button Footswitches are hand-wired by our custom shop and contain USA-sourced wire as well as Carling 110-P Footswitch components.  These are the same spec SPST footswitch components used in the original Fender 2-Button Footswitches.  The result is a robust housing with comfortable action and the most reliable functionality on the market.

The Premium Fender Style Vintage Black 2-Button Footswitch connects to the amplifier via RCA plugs. Cable enters rear of pedal.
Replaces Fender™ part # 0994051000
Part #FBS-322
$59.99




Click on photo for
larger view

Fender™ RCA VIBRATO SHORTING PLUG by Revisit™ - GOLD-PLATED.   Did you know that on vintage Fender™ amps (Blackface, Silverface), the reverb will work without a footswitch plugged in, but the vibrato will not?   This handy-dandy little RCA shorting plug will fix that problem, if you do not own or prefer not to use a footswitch on your vintage 60s or 70s Fender™ amp.   This version is made of gold-plated brass for a low resistance connection and highest immunity to oxidation.  Just plug this little RCA plug gadget into the vibrato footswitch jack on the back panel, and your vibrato will come alive.    Turn the intensity knob to zero to cut out the vibrato when this plug is inserted.  Note:  Does not apply to Bronco, Vibro Champ, Princeton, or Princeton Reverb amps.  Inserting this plug turns the vibrato off in those models, removing the plug turns it on.
Part #FSP-200

$2.50




Click on photo for
larger view

Revisit™ Fender™ STYLE FOOTSWITCH - NICKEL
Aftermarket replacement for the original Fender™ two-button footswitch found on 60s and 70s blackface and silverface amps with vibrato and reverb.  Sturdy
nickel metal construction.    Dual RCA Plugs, 16 ft cable.   Replaces Fender™ part number 0994051000
Part #FBS-271
$34.95



Click on photo for
larger view

Revisit™ Fender™ STYLE FOOTSWITCH - BLACK
Aftermarket replacement for the original Fender™ two-button footswitch found on 60s and 70s blackface and silverface amps with vibrato and reverb.  Sturdy black metal construction.    Dual RCA Plugs, 16 ft cable.
Part #FBS-271-B
$32.95


Click on photo for
larger view

Fender™ STYLE FOOTSWITCH - NICKEL
Aftermarket replacement for the original Fender™ one-button footswitch found on smaller vintage blackface and silverface amps.   Sturdy
nickel metal construction.    Single RCA Plug.
Part #FBS-270
$24.95


Click on photo for
larger view

Fender™ STYLE FOOTSWITCH - BLACK
Aftermarket replacement for the original Fender™ one-button footswitch found on smaller vintage blackface and silverface amps.   Sturdy black metal construction.    Single RCA Plug.
Part #FBS-270B
$27.95


Click on photo for
larger view
FOOT SWITCH, CARLING BRAND, SPST, REPLACEMENT FOR Fender™, ETC.
Carling SPST footswitch. Used in Fender™ etc. Reverb/tremolo/channel switching pedals.  Has 2 electrical terminals (single pole, single throw)Solder lugs for wire.
Part #FS-493
$9.95


Click on photo for
larger view
FOOT SWITCH, CARLING™ BRAND, SPDT
Found in many type of footswitches, including the earlier versions of the Dunlop Crybaby Wah pedals (NOT the version F - see FS-435 below for Crybaby GCB-095F).  Has 3 electrical terminals (single pole, double throw)Solder lugs for wire.
Part #FS-492
$17.50


Click on photo for
larger view

Hex footswitch nut, pack of 4

These replacement nuts fit all Carling brand footswitches and toggle switch and some (but not all) other switches which are not made by Carling.   Carling toggle switches are used in Fender amps.  Hex outer surface (9/16"), M12 thread for 15/32" bushing.

Part HFN-4

$0.99
(for a pack of 4 nuts)


Click on photo for
larger view
SWITCH, CARLING SPST TOGGLE Original replacement for 60s and 70s Fenderpower and standby switches.   Made by Carling
Part #SW-495
$7.50


Click on photo for
larger view
SWITCH, CARLING SPDT 2-POSITION TOGGLE SWITCH, Original Carling replacement for 60s and 70s Fenderground switch.
Part #SW-494
$12.95


Click on photo for
larger view
SAVE WITH MULTIPACK!  3 SWITCHES: Two CarlingSPST toggle switches and one CarlingSPDT toggle switch. Original replacement for 60s and 70s Fender™ Amps (Power, standby, and ground switches). Change the power,  standby, and ground switches on your Fender™ at the same time, and save!
Part #SW-4945
$23.95


Click on photo for
larger view
Capacitor cover for Fender™ Twin Reverb and other full-size Fender™ silverface and blackface amps, such as the Super Reverb, Pro Reverb, Bandmaster and Bassman heads. Mounting centers are 7" x 3.5"   Measurements are 7 1/8" x 3 1/2" x 1 1/4".  Replaces Fender™ part number 0037854000.
Part #CC-170
$34.95

Carbon composition resistors are made by mixing carbon particles with a binder molded into a cylindrical shaped, and then baked.  Standard classic resistor used in vintage amplifiers - Fender™ Blackface and Silverface are prime examples. Fender™ Carbon Comp. Resistors 1/2 Watt
RESISTOR, CARBON COMPOSITION.    New production, 1/2 watt, 3.6mm x 9.5mm.  Lead diameter 0.7mm.  Total length end-to-end 65mm.   Resistors below 100K are 5% tolerance, resistors of 100K and higher are 10% tolerance.  Choose resistor value in Options.

Part #CC1/2-XX

$0.89

Select Option:


Quantity:



Click on photo for
larger view
Revisit™ RESISTOR LEAD FORMING TOOL
You know you want one!   Bend resistors to fit in PC boards, perf boards, or turret boards exactly, uniformly.  Makes your repairs and kit builds look completely professional.   Works great on vintage Fender™ Blackface and Silverface models.   One side is for 1/2 watt resistors, the other side fits 1/4 watt resistors.   Also perfect for diodes.  Slots for radial lead resistors run along the length of the high impact ABS plastic former. Each slot is .05″ longer than the next and has radiused edges to make perfect, square, symmetrical  bends without stressing the leads.
Part #LF-010
$7.50

  Screen Grid & Other
Resistors

RESISTOR, METAL OXIDE FLAMEPROOF, 470 OHM, 2 WATT, INDIVIDUAL.    Commonly used as the screen grid resistor in many tube amps including Fender™.   Available individually, or in packs of 5, below.
Part #470FP2
$0.30 each

RESISTOR, METAL OXIDE FLAMEPROOF, 470 OHM, 2 WATT, PACK OF 5 RESISTORS.    Commonly used as the screen grid resistor in many tube amps including Fender™.
Part #470FP2-5
$1.15
(Pack of 5 Resistors)


RESISTOR, METAL OXIDE FLAMEPROOF, 1000 OHM, 2 WATT, INDIVIDUAL.    Commonly used as the screen grid resistor in many tube amps.  Also used as power supply dropping resistors in many Fender amps™.  Available individually, or in packs of 5, below.
Part #1000FP2
$0.30 each

RESISTOR, METAL OXIDE FLAMEPROOF, 1000 OHM, 2 WATT, PACK OF 5 RESISTORS.    Commonly used as the screen grid resistor in many tube amps.  Also used as power supply dropping resistors in many Fender amps™.
Part #1000FP2-5
$1.15
(Pack of 5 Resistors)


RESISTOR, METAL OXIDE FLAMEPROOF, 2200 OHM, 2 WATT.    Commonly used in the power supply of many Fender™ amps.   Available individually, or in packs of 5, below.
Part #2200FP2
$0.30 each

RESISTOR, METAL OXIDE FLAMEPROOF, 2200 OHM, 2 WATT.    Commonly used in the power supply of many Fender™ amps.
Part #2200FP2-5
$1.15
(Pack of 5 Resistors)


RESISTOR, METAL OXIDE FLAMEPROOF, 4700 OHM, 2 WATT.    Commonly used in the power supply of many Fender™ amps.   Available individually, or in packs of 5, below.
Part #4700FP2
$0.30 each

RESISTOR, METAL OXIDE FLAMEPROOF, 4700 OHM, 2 WATT.    Commonly used in the power supply of many Fender™ amps.
Part #4700FP2-5
$1.15
(Pack of 5 Resistors)


RESISTOR, METAL OXIDE FLAMEPROOF, 10K OHM, 2 WATT.    Commonly used in the power supply of many Fender™ amps.   Available individually, or in packs of 5, below.
Part #10KFP2
$0.30 each

RESISTOR, METAL OXIDE FLAMEPROOF, 10K OHM, 2 WATT.    Commonly used in the power supply of many Fender™ amps.
Part #10KFP2-5
$1.15
(Pack of 5 Resistors)


RESISTOR, METAL OXIDE FLAMEPROOF, 18K OHM, 2 WATT.    Commonly used in the high voltage power supplies of many Fender™ Princeton and Princeton Reverb amplifiers.
Part #18KFP2
$0.30

RESISTOR, METAL OXIDE FLAMEPROOF, 18K OHM, 2 WATT, 5%, PACK OF 5 RESISTORS.    Commonly used in the power supply of many amps.
Part #18KFP2-5
$1.15
(Pack of 5 Resistors)


RESISTOR, METAL OXIDE FLAMEPROOF, 27K OHM, 2 WATT.    Commonly used in the high voltage power supplies of many Fender™ amplifiers.
Part #27KFP2
$0.30

RESISTOR, METAL OXIDE FLAMEPROOF, 27K OHM, 2 WATT, 5%, PACK OF 5 RESISTORS.    Commonly used in the power supply of many amps.
Part #27KFP2-5
$1.15
(Pack of 5 Resistors)


RESISTORS, ULTRA-MINIATURE, 1 WATT, 100K Ohms.    New production, 1 watt, Metal Film Flameproof, 5% tolerance, ultra-miniature.  2.2mm x 6.8mm.  Lead diameter 0.5mm, lead length 28mm.  Total length end-to-end 61mm.   These are 1 watt resistors in a package about the size of a typical 1/4 Watt resistor.  Easy to work with, especially in tight spots.   Made by Yageo.  100K Ohms.    These make excellent replacements for preamp tube plate resistors!
Part #R-MF-UM1W-100K
$0.14

RESISTORS, ULTRA-MINIATURE, 1 WATT, 220K Ohms.    New production, 1 watt, Metal Film Flameproof, 5% tolerance, ultra-miniature.  2.2mm x 6.8mm.  Lead diameter 0.5mm, lead length 28mm.  Total length end-to-end 61mm.   These are 1 watt resistors in a package about the size of a typical 1/4 Watt resistor.  Easy to work with, especially in tight spots.   Made by Yageo.  220K Ohms.  These make excellent replacements for preamp tube plate resistors!
Part #R-MF-UM1W-220K
$0.14

RESISTORS, ULTRA-MINIATURE, 2 WATT.    New production, 2 watt, Metal Film Flameproof, 5% tolerance, ultra-miniature.  3.9mm x 9.0mm.  Lead diameter 0.5mm, lead length 26mm.  Total length end-to-end 61mm.   These are 2 watt resistors in a package about the size of a typical 1/2 Watt resistor.  Easy to work with, especially in tight spots.  Great for screen grid resistors.   Made by Yageo.  Available in 470 ohm, 1K ohm, 2.2k ohm, 4.7K ohm, 10K ohm. All choices in this category are 2 Watts. Choose resistor value in Options.

Part #R-MF-UM-XX
$0.19

Select Option:


Quantity:


Strat™, Stratocaster™, Esquire™, Telecaster™, Tele™, Jazzmaster™, Jaguar™, Mustang™, P.Bass™, J.Bass™ and Fender™ are registered trademarks of Fender™ Musical Instruments. The replacement necks and bodies are for a Fender™ or Squier™ by Fender™ guitar or bass. The distinctive headstock designs and the distinctive body designs of the Stratocaster™, Telecaster™, J.Bass™, P.Bass™ and Tele™ Bass are registered trademarks of Fender™ Musical Instruments Co.
Peavey™ is a registered trademark of Peavey™ Electronics Corporation.
Marshall™ is a registered trademark of Marshall™ Amplification Plc.
Mesa Boogie™ is a registered trademark of MESA/Boogie™ Ltd.
AmpRepairParts.com and Studio Sound Electronics are not affiliated with these companies.
All company names, logos and product names mentioned on these pages are trademarks of their respective owners.

Copyright ©2024 Studio Sound Electronics - All Rights Reserved
Not responsible for web site errors or omissions.
  WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
