We carry a complete selection of Fender™
Amplifier parts for both vintage and modern amps.
For reverb accessories (cables, grommets, transformers,
etc) click here
Back to Fender™ Parts Index
|
|
|
|
Photo |
Description |
Price |
Purchase |
Click on photo for
larger view
 |
Revisit™ Reverb Tank, 17" long, 2 spring, equivalent to Accutronics 4AB3C1B. Input impedance
8 ohms, output impedance 2250 ohms, long decay (2.75 - 4.0 seconds), input insulated/output grounded, designed for horizontal mounting, open side down.
Primarily used by all Fender™
amplifiers with tube reverb from 1963-1990. Also used in Reissue
models like: Fender™ Princeton Reverb, Fender™ Deluxe Reverb,
Fender™ Vibrolux Reverb, Fender™ Pro Reverb, Fender™ Super Reverb , Fender™ Twin
Reverb, Fender™ Quad Reverb , Fender™ Super Six Reverb,
Fender™ Vibrosonic, Fender™ VibroKing, Fender®`63 Reverb Unit Reissue, Fender®`65 Princeton Reverb
Reissue,
Fender®`65 Deluxe Reverb Reissue, Fender®`65 Super Reverb Reissue, Fender®`65
Twin Reverb Reissue, Fender™ `65 Twin Custom(TM) 15, Fender™ Concert Reverb,
Fender™ Twin Amp, Fender™ Concert II, Fender™ Prosonic, Fender™ Dual
Professional.
Also used in Mesa Boogie™ MK2C and others, LAB Series L5, L7, L9,
Koch™ Powertone I, Ampeg VT-40, Ampeg Super Rocket SR212, B-52 AT-100, and
Egnater TourMaster 4100. See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty details
here.
Part #4AB3C1B "Bringing back the sound of vintage Accutronics tanks" |
$43.79 |
|
Click on photo for
larger view
|
Accutronics Reverb Tank, 17" long, 2 spring, 4AB3C1B
current production. Accutronics reverb tanks are a
cheaply produced copy of the Belton tank, and are now made by Belton in South
Korea. They are of much lower quality than the original Accutronics
reverb tanks made in Cary, Illinois until 2009.
Input impedance
8 ohms, output impedance 2250 ohms, long decay (2.75 - 4.0 seconds), input insulated/output grounded, designed for horizontal mounting, open side down.
Primarily used by all Fender™
amplifiers with tube reverb from 1963-1990. Also used in Reissue
models like: Fender™ Princeton Reverb, Fender™ Deluxe Reverb,
Fender™ Vibrolux Reverb, Fender™ Pro Reverb, Fender™ Super Reverb , Fender™ Twin
Reverb, Fender™ Quad Reverb , Fender™ Super Six Reverb,
Fender™ Vibrosonic , Fender®`63 Reverb Unit Reissue, Fender®`65 Princeton Reverb
Reissue,
Fender®`65 Deluxe Reverb Reissue, Fender®`65 Super Reverb Reissue, Fender®`65
Twin Reverb Reissue, Fender™ `65 Twin Custom(TM) 15, Fender™ Concert II, Fender™
Dual Professional.
Also used in Mesa Boogie™ MK2C and others, LAB Series L5, L7, L9,
Koch™ Powertone I, Ampeg™ VT-40, Ampeg™ Super Rocket SR212 and B-52™ AT-100. See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Accutronics products are made in South Korea.
Part #ACC-4AB3C1B |
$39.99 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 2 spring, equivalent to Accutronics 4AB3C1C. Input impedance
8 ohms, output impedance 2250 ohms, long decay (2.75 - 4.0 seconds), input insulated/output grounded, designed for
vertical wall mounting, long axis horizontal, connectors up.
Original Fender™ number 0047604000, used in the Fender™ stand-alone reverb unit,
and the Fender™ `63 Reverb. See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty details
here.
Part #4AB3C1C "Bringing back the sound of vintage Accutronics tanks" |
$43.79 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 2 spring, equivalent to Accutronics 4BB3C1B. Input impedance 150 ohms, output impedance 2250 ohms, long decay (2.75 - 4.0 seconds), input insulated/output grounded, designed for horizontal mounting. Common replacement for Fender™ Blues Deluxe (original 90`s version), Fender™ Blues Deville (original 90`s version).
Also found in Fender™ London Reverb, Harvard Reverb II, Studio Lead, and Showman
115 (1980`s). See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty details
here.
Part #4BB3C1B"Bringing back the sound of vintage Accutronics tanks" |
$43.79 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 2 spring, equivalent to Accutronics
4DB2C1D. Input impedance 250 ohms, output impedance 2250 ohms,
medium decay (1.5 - 2.75 seconds), input insulated/output grounded.
This tank is a common
upgrade tank for the 9" tank in the Fender™ Frontman FM210 and FM212.
See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #4DB2C1D "Bringing back the sound of vintage Accutronics tanks" |
$43.79 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 2 spring, equivalent to Accutronics 4EB3C1B. Input impedance 600 ohms, output impedance 2250 ohms,
long decay (2.75 - 4.0 seconds), input insulated/output grounded, designed for horizontal mounting, open side down. Common replacement for Fender™ Hot Rod Deluxe, Hot Rod Deville, Blues Deluxe Reissue and Blues Deville Reissue.
Also found in Peavey™, Music Man™.
Upgrade for Vox™ AC30CC See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Replaces original Fender™
part number 0050394000.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty
details here.
Part #4EB3C1B "Bringing back the sound of vintage Accutronics tanks" |
$43.79 |
|
Click on photo for larger view
|
Revisit™ Reverb Tank, 9" long, 3 spring, equivalent to Accutronics 8AB2A1B. Short Tank, Medium Decay, input impedance 10 ohms, output 2575 ohms, grounded input and grounded output. Mounts horizontal, open side down.
Found in some Mesa Boogie and
Fender™ Models. See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #8AB2A1B "Bringing back the sound of vintage Accutronics tanks" |
$42.89 |
|
Click on photo for larger view
|
Revisit™ Reverb Tank, 9" long, 3 spring, equivalent to Accutronics 8AB2C1B. Short Tank, Medium Decay, input impedance 10 ohms, output 2575 ohms,
insulated input and grounded output. Mounts horizontal, open side down.
Found in Fender™ Super Champ, and Fender™ Princeton Reverb II. See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #8AB2C1B "Bringing back the sound of vintage Accutronics tanks" |
$42.89 |
|
Click on photo for larger view
|
Revisit™ Reverb Tank, 9" long, 3 spring, equivalent to Accutronics 8BB3C1B.
Short Tank, Long Decay, input impedance
190 ohms, output 2575 ohms, insulated input and grounded output. Used in
the Fender™ Yale Reverb and Harvard Reverb II amps which use the "short" tank.
See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty details
here.
Part #8BB3C1B "Bringing back the sound of vintage Accutronics tanks" |
$42.89 |
|
Click on photo for larger view
|
Revisit™ Reverb Tank, 9" long, 3 spring, equivalent to Accutronics 8DB2C1B.
Short Tank, Medium Decay, input impedance 310 ohms, output 2575 ohms, insulated
input and grounded output. Mounts horizontal, open side down. Primarily used by Fender™ FM212R, FM210R, FM65R, Frontman 212R, Frontman 210R,
Frontman 65R.
See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty details
here.
Part #8DB2C1B "Bringing back the sound of vintage Accutronics tanks" |
$42.89 |
|
Click on photo for larger view
|
Revisit™ Reverb Tank, 9" long, 3 spring, equivalent to Accutronics 8EB2C1B. Short Tank, Medium Decay, input impedance 800 ohms, output 2575 ohms, insulated input and grounded output. Mounts horizontal, open side down.
Used in Fender™ Blues Junior, Fender™ Transistor Amps such as:
Fender™ Deluxe 85, Fender™
Deluxe 90, Fender™ Princeton 65, Fender™ Stage Series, Fender™ Tube 60 Series
(Super 60, Super 112), Fender™ Frontman 65R, Fender™ Eighty-Five, Fender™
Sidekick Reverb 35, Fender™ Sidekick Keyboard 60, Fender™ Ultra Chorus, Fender™
Ultimate Chorus, Fender™ Princeton Chorus, Fender™ Vaporizer, Fender™ Acoustasonic Junior,
Fender™ M-80 HM Series Combo, Peavey Envoy 110, Peavey™ Ultra 60/120,
Peavey™ Backstage, Peavey™ Valveking series etc., Vox™ AC15CC, Vox™ AC15C, and Epiphone™ Valve Junior
Hot Rod, Tech 21™ Trademark 30. This is the most popular short tank.
See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Replaces Fender ™ part numbers 0028055000,
028055, 025269, 020550.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty
details here.
Part #8EB2C1B "Bringing back the sound of vintage Accutronics tanks" |
$42.89 |
|
|
Click on photo for larger view
|
Accutronics Reverb Tank, 9" long, 3 spring, 8EB2C1B.
Accutronics reverb tanks are a budget-priced alternative tank produced in
South Korea by Accu-Bel Sound.
Short Tank, Medium Decay, input impedance 800 ohms, output 2575 ohms, insulated input and grounded output. Mounts horizontal, open side down.
Used in Fender™ Blues Junior, Fender™ Transistor Amps such as:
Fender™ Deluxe 85, Fender™
Deluxe 90, Fender™ Princeton 65, Fender™ Stage Series, Fender™ Tube 60 Series
(Super 60, Super 112), Fender™ Frontman 65R, Fender™ Eighty-Five, Fender™
Sidekick Reverb 35, Fender™ Sidekick Keyboard 60, Fender™ Ultra Chorus, Fender™
Ultimate Chorus, Fender™ Princeton Chorus, Fender™ Vaporizer, Fender™ Acoustasonic Junior,
Fender™ M-80 HM Series Combo, Peavey Envoy 110, Peavey™ Ultra 60/120,
Peavey™ Backstage, Peavey™ Valveking series etc., Vox™ AC15CC, Vox™ AC15C, and Epiphone™ Valve Junior
Hot Rod, Tech 21™ Trademark 30. This is the most popular short tank.
See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Replaces Fender ™ part numbers 0028055000,
028055, 025269, 020550.
Soft mounting grommets are not included
with this tank. If needed, order the RRG-4 grommet set found in
this section.
Accutronics Reverb Tanks are made in South
Korea.
Part #ACC-8EB2C1B |
$35.95
In stock |
|
Click on photo for larger view
|
Revisit™ Reverb Tank, 9" long, 3 spring, equivalent to Accutronics 8EB2C1D. Short Tank, Medium Decay, input impedance 800 ohms, output 2575 ohms, insulated input and grounded output. Mounts
vertical wall, long axis horizontal, connectors down. Used in
Fender™ Acoustasonic Junior, Fender™ M-80 HM Series Head.
See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Replaces original Fender™ part number
0031669000.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.
View the 2-year warranty
details here.
Part #8EB2C1DD "Bringing back the sound of vintage Accutronics tanks" |
$42.89 |
|
Click on photo for larger view
|
Revisit™ Reverb Tank, 9" long, 3 spring, equivalent to Accutronics 8EB3C1B. Short Tank, Long Decay, input impedance 800 ohms, output 2575 ohms, insulated input and grounded output. Mounts horizontal, open side down.
Used as an upgrade in Fender™ Blues Junior, Fender™ Transistor Amps such as:
Fender™ Deluxe 90, Fender™ Princeton 65, Fender™ Stage Series, Fender™ Tube 60
Series (Super 60, Super 112), Peavey™ Ultra 60/120 etc. VOX™ Upgrade for
Vox™ AC15CC and Vox™ AC15C.
See explanation of Accutronics reverb tank numbering system here.
See a chart which lists AC impedance and DC resistance measurements for reverb
tanks here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #8EB3C1B "Bringing back the sound of vintage Accutronics tanks" |
$42.89 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics 9AB2A1B.
Input impedance 10 ohms, output impedance 2575 ohms, medium decay (1.5 - 2.75
seconds), input and output grounded, designed for horizontal mounting, open side
down. Common replacement for Mesa Boogie™.
Also used in some Fender™, Vox™ AC30 (1960s+70s),
and
Engl Screamer (E330, E335) See explanation of Accutronics reverb tank numbering system here. See a
chart which lists AC impedance and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #9AB2A1B
"Bringing back the sound of vintage Accutronics tanks" |
$48.99 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics 9AB3A1B.
Input impedance 10 ohms, output impedance 2575 ohms, long decay (2.75 - 4
seconds), input and output grounded, designed for horizontal mounting, open side
down. A longer decay replacement for Mesa Boogie™
Also may be used in some Fender™, Vox™ AC30 (1960s+70s),
and
Engl™
Screamer (E330, E335) See explanation of Accutronics reverb tank numbering system here. See a
chart which lists AC impedance and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #9AB3A1B
"Bringing back the sound of vintage Accutronics tanks" |
$48.99
In stock |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics 9AB2C1B. Input impedance 10 ohms, output impedance 2575 ohms, medium decay (1.5 - 2.75 seconds), input insulated/output grounded, designed for horizontal mounting, open side down. Common replacement for
Fender™. See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #9AB2C1B
"Bringing back the sound of vintage Accutronics tanks" |
48.99 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics 9AB3C1B. Input impedance 10 ohms, output impedance 2575 ohms,
long decay (2.75 - 4 seconds), input insulated/output grounded, designed for horizontal mounting, open side down. Common replacement for
Fender™.
Upgrade for the 4AB3C1B 2-spring tank. See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #9AB3C1B
"Bringing back the sound of vintage Accutronics tanks" |
$48.99 |
|
Click on photo for
larger view
 |
Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics
9AB3C1C.
Input impedance 10 ohms, output impedance 2575 ohms, long decay (2.75 - 4
seconds), input insulated/output grounded, designed for vertical mounting. A longer decay replacement for
the Fender 6G15 Reverb Unit (1960s).
See explanation of Accutronics reverb tank numbering system here. See
a chart which lists AC impedance and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #9AB3C1C
"Bringing back the sound of vintage Accutronics tanks" |
$48.99
In stock |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics 9EB2C1B. Input impedance 800 ohms, output impedance 2575 ohms, medium decay (2.75-4.0 seconds), input insulated/output grounded, designed for horizontal mounting, open side down. Common replacement for Peavey™Nashville 112, Vox™ AC50CPH, AC100CPH,
upgrades Vox™ AC30CC, deeper reverb for the Fender™ Hot Rod Deluxe/DeVille! See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #9EB2C1B "Bringing back the sound of vintage Accutronics tanks" |
$48.99 |
|
Click on photo for
larger view
|
Revisit™ Reverb Tank, 17" long, 3 spring, equivalent to Accutronics 9FB2A1C. Input impedance
1475 ohms, output impedance 2575 ohms, medium decay (2.75-4.0 seconds), input
grounded/output grounded, designed for vertical mounting, long axis horizontal,
connectors up. Common replacement for
Fender, Peavey, Music Man, Gemini,
Portaflex. Upgrade for the Marshall™ Model 2205. See explanation of Accutronics reverb tank numbering system here. See a chart which lists AC impedance
and DC resistance measurements for reverb tanks
here.
Unlike some tanks, Revisit™ Reverb Tanks include the soft mounting grommets to acoustically decouple the outer channel from the amplifier cabinet.View the 2-year warranty
details here.
Part #9FB2A1C "Bringing back the sound of vintage Accutronics tanks" |
$48.99 |
|
Click on photo for
larger view |
Rubber mounting grommets for
reverb tanks, package of four. Provides shock absorption for
tanks mounted directly to the inside of a wooden amp cabinet. Mounting
Hole Diameter = 3/8" Outer Diameter = 1/2"
Part #RRG-4 |
$1.99
(For a pack of 4 grommets)
In stock |
|
Click on photo for
larger view |
T RANSFORMER, Fender™ REVERB DRIVER. Reverb
transformer as found in the Fender™ 65 Twin Reverb Reissue, 65 Super Reverb
Reissue, 65 Princeton Reverb Reissue, and 65 Deluxe Reverb Reissue.
Fender™ part number 0037099049. 10" leads with .187 faston
connectors, X-Mount with 1 3/4" mounting centers.
Part #037099 |
$39.95 |
|
Click on photo for
larger view |
TRANSFORMER,
Revisit™ Fender™ REVERB DRIVER. For vintage blackface and silverface Deluxe Reverb, Princeton Reverb, Twin Reverb, Pro Reverb, Super Reverb, Vibrolux Reverb, etc. Equivalent to Fender™
#125A20B & #022921. For vintage Mesa-Boogie™ models, including
vintage Mark I through Mark IV, Subway Blues, Studio 22, Studio Caliber,
Maverick, Lonestar Special, and many others . Mesa Boogie™
part number 550185. 10" cut leads, X-Mount with 1 3/4" mounting
centers. Input impedance 14.5K ohms, output impedance 4 ohms.
Part #TGR-001 |
$20.95 |
|
Click on photo for
larger view |
Fender™ Reverb Cable. Molded
plastic right-angle dual RCA on both ends. This cable is used on the 65 Super
Reverb Reissue, 64 Vibroverb Custom and
several other models. 48" long Fender™ part number 0056931000.
Part #RC-310 |
$5.95
In Stock |
|
Click on photo for
larger view |
3 foot Revisit™ right angle RCA cables for Reverb Tanks and other electronic devices.
Dual cable, excellent shielding properties, 3 feet long.
Part #RC-173 |
$8.95
In Stock |
|
|
Click on photo for
larger view |
4 foot Revisit™ right angle RCA cables for Reverb Tanks and other electronic devices.
Dual cable, excellent shielding properties, 4 feet long.
Part #RC-174 |
$8.95
In stock |
|
|
Click on photo for
larger view |
5 foot Revisit™ right angle RCA cables for Reverb Tanks and other electronic devices.
Dual cable, excellent shielding properties, 5 feet long.
Part #RC-175 |
$8.95
In stock |
|
|
Click on photo for
larger view |
Revisit™ vintage Fender™ style
reverb cable - universal. Made
with the same style shielded wire and RCA connectors as the originals.
Warning: Not designed for use in amps other than Fender, due to the
bare shields. These reverb cables perfectly replicate the original cables found in vintage
Fender™ vintage blackface and some silverface amplifiers. One cable is 3 ft
long, and the other is 5 ft long. By coiling up any excess cable into the
reverb isolation bag, these cable lengths are suitable for most vintage Fender™
combo amps, with these exceptions: Super Reverb, Quad Reverb, Super Six
Reverb.
Part #RC-200 |
$29.95
In stock |
|
|
Click on photo for
larger view |
Revisit™ vintage Fender™ style
reverb cable KIT for Super Reverb, Quad Reverb, and Super Six Reverb (blackface
and early silverface). Long length for larger amplifiers. Set of
parts for you to make two cables (reverb input and reverb
output) Short one is 43 inches (110 cm), long one is 55 inches (140
cm).
Open face
braided shielded cable with metal RCA ends that you install - near-duplicate of the original O.E.M.
Fender™ cables used in the 1960s.
Compare with similar cable sets costing up to $45.
Warning: Not designed for use in amps other than Fender, due to the bare
shields.
Instructions not included - assumes you are familiar with building this type of
cable. Soldering skills and tools required.
Part #RK-279L |
$15.95
In stock
Assembly required (with soldering skills needed) |
|
|
Click on photo for
larger view |
Revisit™ vintage Fender™ style
reverb cable KIT for Twin Reverb, Pro Reverb and Vibrosonic Reverb (blackface
and early silverface). Medium length for medium-sized amplifiers. Set of
parts for you to make two cables (reverb input and reverb
output) Short one is 39 inches (99 cm), long one is 51 inches (130 cm).
Open face
braided shielded cable with metal RCA ends that you install - near-duplicate of the original O.E.M.
Fender™ cables used in the 1960s.
Compare with similar cable sets costing up to $45.
Warning: Not designed for use in amps other than Fender, due to the bare
shields.
Instructions not included - assumes you are familiar with building this type of
cable. Soldering skills and tools required.
Part #RK-279M |
$14.95
In stock
Assembly required (with soldering skills needed) |
|
|
Click on photo for
larger view |
Revisit™ vintage Fender™ style
reverb cable KIT for Deluxe Reverb, Vibrolux Reverb and Princeton Reverb (blackface
and early silverface). Short length for smaller amps. Set of
parts for you to make two cables (reverb input and reverb
output) Short one is 36 inches, long one is 47 inches.
Open face
braided shielded cable with metal RCA ends that you install - near-duplicate of the original O.E.M.
Fender™ cables used in the 1960s.
Compare with similar cable sets costing up to $45.
Warning: Not designed for use in amps other than Fender, due to the bare
shields.
Instructions not included - assumes you are familiar with building this type of
cable. Soldering skills and tools required.
Part #RK-279S |
$13.95
In stock
Assembly required (with soldering skills needed) |
|
Click on photo for
larger view |
 Fender™ style
reverb or AC cable clamp. Used on Fender amps since the early 60s to
hold the reverb cable to the side of the cabinet. Clamp is 3/8"
diameter, comes with 3/4" screw for mounting. Also used in some amplifiers
to hold the AC cord to the cabinet wall. Fender part number 022941.
Works on many other brands of amplifiers as well.
Part #RCC-381 |
$0.99
In stock |
|
Click on photo for
larger view |
Fender™ Reverb Cable. Molded
plastic straight dual RCA on both ends. This cable is used on the `65 Twin
Reverb Reissue, `65 Princeton Reverb Reissue, `65 Deluxe Reverb Reissue and
probably some others. 36" long, Fender™ part number 0025722000.
Part #RC-300 |
$5.95
In stock |
|
Click on photo for
larger view |
Fender™ Reverb Cable. Molded
plastic right-angle dual RCA on both ends. This cable is used on the `65 Super
Reverb Reissue, `64 Vibroverb Custom and
probably some others. 48" long, Fender™ part number 0056931000.
Part #RC-310 |
$5.95
In Stock |
|
Click on photo for
larger view
|
 Reverb Tank Bag for 17"
tanks. Used in a variety of amps, including Fender™ amps. Works with any long
(17") reverb tank. Mounting screws not included. Reverb
bags give the reverb tank better isolation which results is fuller, richer
reverb and less feedback.
Part #RB-017 |
$18.90
In Stock |
|
Strat™, Stratocaster™, Esquire™, Telecaster™, Tele™, Jazzmaster™, Jaguar™, Mustang™, P.Bass™, J.Bass™ and Fender™ are registered trademarks of Fender™ Musical Instruments. The replacement necks and bodies are for a Fender™ or Squier™ by Fender™ guitar or bass. The distinctive headstock designs and the distinctive body designs of the Stratocaster™, Telecaster™, J.Bass™, P.Bass™ and Tele™ Bass are registered trademarks of Fender™ Musical Instruments Co.
Peavey™ is a registered trademark of Peavey™ Electronics Corporation.
Marshall™ is a registered trademark of Marshall™ Amplification Plc.
Mesa Boogie™ is a registered trademark of MESA/Boogie™ Ltd.
AmpRepairParts.com and Studio Sound Electronics are not affiliated with these companies.
All company names, logos and product names mentioned on these pages are trademarks of their respective owners.
Copyright ©2024 Studio Sound Electronics - All Rights Reserved
Not responsible for web site errors or omissions.
WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
|
