Fender™ Capacitor Kits


Click on photo for
larger view
Fender™ Electrolytic Capacitor Kits

Fender capacitor kits contain all of the main filter, decoupling filter, bias filter and preamp cathode bypass electrolytic capacitors for most amps from the blackface and silverface eras.
Prices starting at $32.95 Click here to see the full selection of Fender capacitor kits.
  Fender™ Potentiometer Sets


Click on photo for
larger view
Fender™ Potentiometer Sets

Fender potentiometer sets contain all of the potentiometers for a particular amplifier.    Large selection for many models from the 1950s up to the present day.  Most potentiometer sets for amps in the blackface and silverface era offer a choice of metal shafts or nylon shafts.   Many kits for 60s and 70s models include the resistors which are soldered directly to the pots.
Prices starting at $12.95 Click here to see the full selection of Fender potentiometer sets.
  Fender™ Front Panel Rehab Kits for Vintage Blackface & Silverface (60s & 70s)


Click on photo for
larger view
Fender™ Front Panel Rehab Kit for one channel amplifiers    For vintage Fender™ amps made before 1980 from the original blackface and silverface eras.  Not for reissues.  Contains two Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus two 100 ohm, two 68K and one 1 Meg carbon composition resistors.  Also contains a new bright switch with screws, and a new pilot light (your choice of color.   Scratchy, intermittent jacks and bright switch?   Pilot light dim, or intermittent?   This kit will take care of those problems.   Add a Potentiometer Kit for a complete front panel component replacement.  (Note:  On Bronco, Champ and Vibro Champ, the Switchcraft switch in this kit replaces the power switch).   Select lamp jewel color in options.   Fits the following one-channel amplifiers:   Bronco AB764 (1967-1975), Champ AA764 (1964-1982, both blackface and silverface),  Princeton (1963-1979), Princeton Reverb (1964-1981), VibroChamp AA764 (Blackface 1964-67, Silverface 1968-1982).  Select lamp jewel color in options.
Part #FPRK-1-X
$19.50

Select Option:


Quantity:



Click on photo for
larger view
Fender™ Front Panel Rehab Kit for two channel amplifiers    For vintage Fender™ amps made before 1980 from the original blackface and silverface eras.  Not for reissues.  Contains four Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus four 68K and two 1 Meg carbon composition resistors.  Also contains two new bright switches with screws, and a new pilot light (your choice of color).   Scratchy, intermittent jacks and bright switch?    Pilot light dim, or intermittent?   This kit will take care of those problems.   Add a Potentiometer Kit for a complete front panel component replacement.
Bandmaster (1964-1975), Bandmaster Reverb (1968-1980), Bantam Bass (1969-1971), Bassman (1964-1982), Bassman 10 (Silverface 1972-1982), Concert (1964-1965 Blackface), Deluxe (1963-1966), Deluxe Reverb (1963-1982), Dual Showman (1967-69 Silverface), Dual Showman Reverb (1968-1981), Pro (1964-1965 Blackface), Pro Reverb (1965-1982 Blackface and Silverface), Quad Reverb (1972-1979 Silverface) Showman (1964-1967 Blackface), Showman (1968-1970 Silverface), Super Reverb (1963-1981 Blackface and Silverface), Super Six Reverb (1972-1979), Tremolux (1964-1966 Blackface), Twin Reverb (1963-1982 Blackface and Silverface), Vibrolux (1964 Blackface), Vibrolux Reverb (1964-1982 Blackface and Silverface), Vibrosonic (1972-1981 Silverface), Vibroverb (1964 Blackface).

Select lamp jewel color in options.

Part #FPRK-2-X
$30.95

Select Option:


Quantity:

  Fender™ Input Jack Replacement Kits for Vintage Tweed, Blonde, Brown, Blackface & Silverface (50s, 60s & 70s)


Click on photo for
larger view
Fender™ Input Jack Replacement Kit for one channel amplifiers (or for just one channel of a two-channel amp).    For vintage Fender™ amps made before 1980 from the original tweed, blonde, brown, blackface and silverface eras.  Contains two Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus two 68K and one 1 Meg carbon composition resistors.   This is the input circuit replacement kit for the following one-channel amplifiers:   Bronco AB764 (1967-1975), Champ AA764 (1964-1982, both blackface and silverface), Champ 5E1 (1955-1956), Champ 5F1 (1956-1964), Princeton (1963-1979), Princeton Reverb (1964-1981), VibroChamp AA764 (Blackface 1964-67, Silverface 1968-1982).   Note:   Does NOT work with the Fender Super Twin, 300PS, or Fender 75.
Part #FJK-1
$9.95



Click on photo for
larger view
Fender™ Input Jack Replacement Kit for two channel amplifiers.    For vintage Fender™ amps made before 1980 from the original tweed, blonde, brown, blackface and silverface eras.  Contains four Switchcraft 12A switched jacks, with nuts, locking washer and trim washer, plus four 68K and two 1 Meg carbon composition resistors.   This is the input circuit replacement kit for the following two-channel amplifiers:   Bandmaster (1956-1975), Bandmaster Reverb (1968-1980), Bantam Bass (1969-1971), Bassman (1961-1982), Bassman 10 (Silverface 1972-1982), Concert (1959-1965 Brown and Blackface), Deluxe (1963-1966), Deluxe Reverb (1963-1982), Dual Showman (1967-69 Silverface), Dual Showman Reverb (1968-1981), Harvard 6G10 (1955-1962 Tweed), Pro (1960-1965 Brown and Blackface), Pro Reverb (1965-1982 Blackface and Silverface), Quad Reverb (1972-1979 Silverface) Showman (1960-1967 Blonde and Blackface), Showman (1968-1970 Silverface), Super (1960-1963 Brown), Super Reverb (1963-1981 Blackface and Silverface), Super Six Reverb (1972-1979), Tremolux (1955-1966 Tweed, Blonde and Blackface), Twin (1958-1963 Tweed and Blonde), Twin Reverb (1963-1982 Blackface and Silverface), Vibrosonic (1959-1963 Brown), Vibrolux (1961-1964 Brown and Blackface), Vibrolux Reverb (1964-1982 Blackface and Silverface), Vibrosonic (1972-1981 Silverface), Vibroverb (1963-1964 Brown and Blackface).
Part #FJK-2
$19.95



  Fender™ Rear Panel Jack Replacement Kits for Vintage  Blackface & Silverface (60s & 70s)


Click on photo for
larger view
Fender™ Rear Panel Jack Replacement Kit for Blackface and Silverface amps (1960s/1970s)   For vintage Fender™ amps made before 1980 from the original blackface and silverface eras.   For all models which have both Vibrato and Reverb, and whose back panel looks similar to the one shown below.   Contains the two speaker jacks and the four reverb/vibrato RCA jacks.

Part #FRJK-1

$14.95

  Fender™ Power Tube Socket Replacement Kits for Vintage Blackface & Silverface (60s & 70s)

Click on photo for
larger view
Fender™ Vintage Amp (60s Blackface and 70s Silverface) Power Tube Socket replacement kit.    For vintage Fender™ amps (NOT Reissues!) from the original blackface and silverface eras which have two power tubes (6L6 or 6V6).   Contains two phenolic 8-pin sockets, two "bear trap" retainers, four mounting screws, two 470 ohm screen grid resistors (Metal-Film Flameproof for safety), and two carbon composition 1500 ohm control grid resistors.   Princeton and Princeton Reverb do not need the resistors.   Perfect for Vibrolux Reverb, Vibroverb, Super Reverb, Deluxe Reverb, Pro Reverb, Bassman, Bandmaster Reverb, Tremolux, etc.
Part #FPTSK-2
$13.95


Click on photo for
larger view
Fender™ Vintage Amp (60s Blackface and 70s Silverface) Power Tube Socket replacement kit.    For vintage Fender™ amps (NOT Reissues!) from the original blackface and silverface eras which have four power tubes (6L6).   Contains four phenolic 8-pin sockets, four "bear trap" retainers, eight mounting screws, four 470 ohm screen grid resistors (Metal-Film Flameproof for safety), and four carbon composition 1500 ohm control grid resistors.   Perfect for Twin Reverb, Showman and Dual Showman, Quad Reverb, Bassman 100, etc.
Part #FPTSK-4
$26.95

  Fender™ Vibrato Rebuild Kits and other parts for the Vibrato circuit.   Vintage Blackface & Silverface (1963-1981)


Click on photo for
larger view
Fender™ VIBRATO REBUILD KIT by Revisit™
For all vintage blackface and silverface Fender amplifiers with opto-isolator type vibrato from the 1963-1981 era (not reissue models).  This would include most all 60s and 70s Fender amps with vibrato except for the Bronco, Vibro-Champ, Princeton, or Princeton Reverb - kit will not work on those models.  If you have vibrato problems, changing the vibrato 12AX7 oscillator tube should be the first step (2nd preamp tube away from the power tubes).   If that does not solve the problem, changing the components contained in this kit should do the trick.   Contains 3 phase shift ceramic disc capacitors, two resistors and one opto-isolator.   More info here.
Part #VRK-1
$16.95


Click on photo for
larger view
Fender™ VIBRATO OPTOISOLATOR LDR ("BUG")
Used in the vibrato circuit of vintage Fender™  Blackface and Silverface amps.  Replaces Fender™ part number 0037836000

Part #LDR-1020
$9.95


CAPACITOR, CERAMIC DISC, RADIAL.
  Replacement for the ceramic disc vibrato phase shift capacitors in vintage Blackface and Silverface Fender™ amplifiers from the 60s and 70s.   Rated at 500 volts.  Available in .01uF and .02uF (See Options to select value)   Tips:  (1) If you would like to slow down the vibrato speed range (popular for jazz players):  There are three caps in the vibrato phase shift circuit - two .01s and a .02.  You can slow the vibrato speed down by replacing the .01s with .02s (so that all three ceramic disc caps are .02).  (2) Background ticking sound in the vibrato?   Install a .02 cap from ground to the leg of the optoisolator that connects to the 10 Meg resistor (brown/black/blue).

Part #C-CD-XX
$0.75

Select Option:


Quantity:


Click on photo for
larger view

Fender™ RCA VIBRATO SHORTING PLUG by Revisit™ - GOLD-PLATED.   Did you know that on vintage Fender™ amps (Blackface, Silverface), the reverb will work without a footswitch plugged in, but the vibrato will not?   This handy-dandy little RCA shorting plug will fix that problem, if you do not own or prefer not to use a footswitch on your vintage 60s or 70s Fender™ amp.   This version is made of gold-plated brass for a low resistance connection and highest immunity to oxidation.  Just plug this little RCA plug gadget into the vibrato footswitch jack on the back panel, and your vibrato will come alive.    Turn the intensity knob to zero to cut out the vibrato when this plug is inserted.  Note:  Does not apply to Bronco, Vibro Champ, Princeton, or Princeton Reverb amps.  Inserting this plug turns the vibrato off in those models, removing the plug turns it on.
Part #FSP-200

$2.50





Fender™ Jewel Kits




Click on photo for
 larger view
REPLACEMENT PILOT LAMP JEWEL KIT, Fender™, Peavey™, Mesa/Boogie™ , many others.   Kit of 6 jewels - change your light color as often as you like.   Contains one each red, amber, green, blue, violet and clear.
Part #JLK-115
$14.99



Fender™ Switch Kits



Click on photo for
larger view
SAVE WITH MULTIPACK!  3 SWITCHES: Two CarlingSPST toggle switches and one CarlingSPDT toggle switch. Original replacement for 60s and 70s Fender™ Amps (Power, standby, and ground switches). Change the power,  standby, and ground switches on your Fender™ at the same time, and save!
Part #SW-4945
$23.95



Fender™ Knob Sets



Click on photo for
larger view
KNOB, Fender™ Style, Vintage Cream, Set of 6
Replaces Fender™ part number 0990933000.  "Fender™ Barrel" knob, cream white with brass inset and set-screw as used by:  Fender™ 1960-1964 for the Fender™ Bassman, Showman and Bandmaster Amp, and for several Fender™ Custom Shop and Fender™ Reissue amps:  Tone Master, Custom Vibrolux Reverb, Vibroking, Super Sonic Amp (blonde) etc.  Set of 6 knobs.
Part #K-315-6
$12.95
(for pack of 6 knobs)


  Fender™ Amp Trim Refurb Kits


Click on photo for
 larger view

Fender™ LARGE COMBO AMP COSMETIC REFURB KIT
For original 1960s blackface and pre-1975 silverface Fender™ Twin Reverb, Super Reverb, Pro Amp, Pro Reverb, Concert, Vibrosonic models which use 5 5/8" long chassis straps.   (Not designed for the Blackface or Silverface REISSUES.   NOT for vintage Fender™ Speaker Cabinets or Heads, such as Bassman, Bandmaster, Showman, Tremolux, etc.   Not for the Bassman Ten Combo.)    Model not listed? - Contact us.   Not for amps made after 1974, not for reissued blackface and silverface amps.  Contains original Fender™ handle with mounting hardware, 5 5/8" chassis straps with bolts and keps nuts,
nickel 15/16" glides, set of cabinet corners with mounting screws.   Spruce up the looks of your vintage  amp!    For additional refurbishing, see the Fender™ logo plates here, Fender™ knobs here, Fender™ lamp jewels here and Fender™ casters here
Part #FRK-5
$34.95





Click on photo for
 larger view
Fender™ MEDIUM COMBO AMP COSMETIC REFURB KIT  For original 1960s blackface and pre-1975 silverface Fender™ Deluxe, Deluxe Reverb, Princeton, Princeton Reverb, Tremolux, Musicmaster Bass, Vibrolux Reverb models which use 4 5/8" long chassis straps.   (Not designed for the Blackface or Silverface REISSUES.   NOT for vintage Fender™ Speaker Cabinets or Heads, such as Bassman, Bandmaster, Showman, Tremolux, etc.   Not for the Bassman Ten Combo.)   Model not listed? - Contact us.   Not for amps made after 1974, not for reissued blackface and silverface amps.  Contains original Fender™ handle with mounting hardware, 4 5/8" chassis straps with bolts and keps nuts, nickel 15/16"  glides, set of cabinet corners with mounting screws.   Spruce up the looks of your vintage  amp!    For additional refurbishing, see the Fender™ logo plates here, Fender™ knobs here, Fender™ lamp jewels here and Fender™ casters here
Part #FRK-4
$33.95



Click on photo for
 larger view
Fender™ SMALL COMBO AMP COSMETIC REFURB KIT  For original 1960s and pre-1975 silverface Fender™ Champ, Vibro Champ, Bronco models which use 3 5/8" long chassis straps.    Model not listed? - Contact us.   Not for amps made after 1974, not for reissued blackface and silverface amps.  Contains original Fender™ handle with mounting hardware, 3 5/8" chassis straps with bolts and keps nuts, nickel 15/16" glides.   Spruce up the looks of your vintage  amp!    For additional refurbishing, see the Fender™ logo plates here, Fender™ lamp jewels here and Fender™ knobs here
Part #FRK-3
$26.95


Pots for Blonde and Brown Series Amps from
1960-1963 (Brownface)
(Not Reissues)
Fender amps from 1960-1963 underwent many design changes, as Leo Fender was in a period of experimentation to achieve the ultimate Fender sound, so it is very difficult to assemble accurate Potentiometer Kits.   We do offer these individual pots which cover most of the needs of the "brownface" era.    For the model number and version, look on the tube chart in the back of the amp.


Click on photo for
larger view
POT - Revisit™, 24MM, SOLID SHAFT
24 mm carbon composition, 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 3/8" diameter bushing, solder lugs. For hand-wired American made amplifiers such as vintage Fender™ and others.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-XX
Starting at
$2.95
Select Option:

Quantity:



Click on photo for
larger view
POT - Revisit™, 24MM, SOLID SHAFT, 3M & 10M REVERSE AUDIO
24 mm carbon composition, 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 8mm diameter bushing, solder lugs. For hand-wired American made amplifiers such as vintage Fender™ and others.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-XX
Starting at
$3.95
Select Option:

Quantity:



Click on photo for
larger view
POT -  Revisit™ , 350K AUDIO WITH 70K TAP, 9MM BUSHING, FENDER™ BROWNFACE SERIES TREBLE POT
16mm carbon composition. 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 9mm" bushing, solder lugs. Special manufacture, to replace the treble pots on certain Fender™ 1961-1963 Brownface models, such as Bassman 6G6, Concert 6G12A, Pro 6G5A, Showman 6G14, Super 6G4A, Tremolux 6G9, Vibrolux 6G11, and the Vibroverb 6G16.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-350KA-70KT
$4.95


Pots for Original Tweed Amps from 1947-1959
(Not Reissues)



Click on photo for
larger view
POT - Revisit™, 24MM, SOLID SHAFT
24 mm carbon composition, 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 3/8" diameter bushing, solder lugs. For hand-wired American made amplifiers such as vintage Fender™ and others.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-XX
Starting at
$2.95
Select Option:

Quantity:



Click on photo for
larger view
POT - Revisit™, 24MM, SOLID SHAFT, 3M & 10M REVERSE AUDIO
24 mm carbon composition, 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 8mm diameter bushing, solder lugs. For hand-wired American made amplifiers such as vintage Fender™ and others.   For a downloadable pot cross-reference for Fender brownface models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-XX
Starting at
$3.95
Select Option:

Quantity:


Click on photo for
larger view
POT - 1 MEG AUDIO TAPER, 3/8" BUSHING, WITH SPST ROTARY SWITCH
24 mm carbon composition. 300° rotation. 1/2 watt, 500VDC rating. 1/4" diameter shaft, 3/8" bushing, solder lugs, with rotary SPST (two terminal) switch.  Replacement for the volume control with AC switch on the 5C1 Champ, 5E1 Champ, 5F1 Champ, 5B3 Deluxe.   Replacement for the tone control with AC switch on the 5B2 Princeton, 5C2 Princeton, and 5D2 Princeton.  For a downloadable pot cross-reference for Fender tweed models, click here.
INCLUDES NUT & WASHER
Part #P-FBF-1MA-RS
$4.95

Fender™ Modification Kits



(Picture for illustrative purposes only - actual kit components will vary from this photo)

FENDER "BLACKFACE" KIT by Revisit™  This kit changes the circuit design of your late 60s or 70s vintage Silverface Fender™ Amp to the original "Blackface" amps of the early-to-mid 60s.   Most players agree that the pre-CBS blackface amps sounded much better than the silverface successors designed by the CBS engineers.   With this kit, you can take your amp back to the Leo Fender design.  In addition, you also restore the bias-setting capability of the amp in place of the "balance" control.   These modifications are completely reversible, and no permanent changes to the chassis (such as drilling holes, etc) are required.  The kit includes 9 resistors, 4 capacitors and instructions.  Note:  This kit does NOT apply to the silverface Bantam Bassman, Bassman, Bassman Ten, Bronco, Champ, Deluxe Reverb, Musicmaster Bassman, Princeton Reverb, or VibroChamp.

Part #FBK-1

$11.95


(Picture for illustrative purposes only - actual kit components will vary from this photo)

FENDER "S-L-O-W-E-R  VIBRATO" KIT by Revisit™ FOR VINTAGE BLACKFACE AND SILVERFACE  This kit changes the circuit design of the vibrato to slow down the slow end of the vibrato speed control considerably, giving a much wider usable speed range.    Fast speed remains virtually unchanged, and the intensity remains the same.   Jazz players especially love the slower vibrato.  The official Fender vibrato "tick cure" is also included in this kit, as listed on a Fender service bulletin from several years ago.   This kit is applicable to all two-channel vintage Blackface and Silverface amps from the 1960-1970 era.   This kit does not apply to Bronco, Princeton or VibroChamp circuits.  Kit includes necessary parts and instructions.   Soldering capability is required.

Part #FSVK-100

$3.50


(Picture for illustrative purposes only - actual kit components will vary from this photo)

FENDER "S-L-O-W-E-R  VIBRATO" KIT  by Revisit™ FOR REISSUE AMPS This kit changes the circuit design of the vibrato to slow down the slow end of the vibrato speed control considerably, giving a much wider usable speed range.    Fast speed remains virtually unchanged, and the intensity remains the same.  Fits `65 Twin Reverb™ Reissue, `65 Super Reverb™ Reissue, `65 Deluxe Reverb™ Reissue, '65 Princeton Reverb™ Reissue, `68 Custom Twin Reverb™, `65 Custom Super Reverb™, `68 Custom Deluxe Reverb™, '68 Custom Princeton Reverb™.  Kit includes necessary parts and instructions.   Soldering capability is required.

Part #FRSVK

$1.25
