Description

Click on photo for
larger view

NSC018343 Dimensions.
Click on diagram for larger view

Replacement output transformer for most Blackface and Silverface Fender amps with 40 watt or 50 watt power. Replaces Fender part numbers 125A9A*, 018343, 022855, 002871, 0036485000, 0036968000, 0041754000, 0064420000, and 0073304000.   Used in vintage Bassman ('59 Tweed, Blonde, Blackface, Silverface).  Used in Concert II.  May be used to upgrade vintage Bandmaster Reverb*, Pro Reverb*, Super Reverb* or Vibrolux Reverb* models (*drilling new chassis holes required!)  Fits Hot Rod Deville, Blues Deville (all versions).   Fits Reissue Models: '65 Super Reverb, '68 Custom Super Reverb, '63 Vibroverb, '64 Custom Vibroverb, '68 Custom Vibrolux, Eric Clapton Twinolux. Transformer made in Chicago, Illinois, USA by Magnetic Components.

Important:   Not for Ultralinear Silverface Models with 70 Watt output!   Ultralinear types are Bandmaster Reverb, Pro Reverb and Super Reverb models from 1976-1981.   These models are easily identified by the 70W RMS labelling by the speaker jack, and they all had a Master Volume with pull switch.

*Note:  Some vintage Fender models listed above may have smaller transformers with only 2 mounting holes.   This transformer is an upgrade for those, but DOES require that 4 new 3/16" holes be drilled into the chassis in order to mount this transformer.

For newer amplifiers which use quick-connect terminals to connect the primary red, blue and brown wires to the PC board, see the FC-61253 pack of quick-connect terminals below (FC-6125-3).

Download the wiring diagram by model for the NSC018343.   In some cases, the wire colors will differ from the original transformer.

Part #NSC018343

$129.95

Click on photo for
larger view

W022889 Dimensions
Click on diagram for more information

Replacement output transformer for most vintage Blackface and Silverface Fender amps with 100 watt power. Replaces Fender part numbers 125A29A, 022889.   Used in vintage Fender Twin, Twin Reverb, Dual Showman, Dual Showman Reverb, Super 6 Reverb, Showman, Quad Reverb, PA-100, and Bassman 100 models made before 1976.

Important:   Not for Ultralinear Silverface Models with 135 Watt output!   Ultralinear types are the Twin Reverb, Bassman 135 and PA135 models from 1976-1981.   These models are easily identified by the 135W RMS labelling by the speaker jack, and they all had a Master Volume with pull switch.

Part #W022889

$139.95

Click on photo for
larger view

Replacement original style output transformer for most vintage Blackface and Silverface Fender Bandmaster Reverb, Pro Reverb, Tremolux and Vibrolux Reverb amps with 40 watt output power.  Replaces Fender part numbers 125A6A, 125A7A, 022830, and 022848.

4000 Ohm Center-Tapped Primary, 4 Ohm secondary.  Standard 2-hole mounting, 92mm (3-5/8") center-to-center.  Standard blue-red-brown primary, green-black secondary wiring color code.

Part #W022848

$89.95

Click on photo for
larger view

Replacement original style output transformer for vintage Blackface and Silverface Fender Tweed Princeton, Blackface Princeton and Blackface or Silverface Princeton Reverb amps with 15 watt output power. Replaces Fender part numbers 125A10B and 022913.

8000 Ohm Center-Tapped Primary, 8 Ohm secondary.  Standard 2-hole mounting, 71.4mm (2-13/16") center-to-center.  Standard blue-red-brown primary, green-black secondary wiring color code.

Click here to download specifications.

Part #W022913

$89.95


Click on photo for
larger view

Fits all versions of the Blues Junior, and fixes the shortcomings of the original output transformer   Flaws like woofy, flabby or farty tone are a thing of the past. Overdrive tones are sweeter, harmonics are richer. Frequency response extends well past the range of hearing, so nothing is left behind.

Output transformers seldom make an amp louder; they’re mostly about tone quality. But they do improve headroom by reducing distortion.

6600 Ohm Center-Tapped Primary, 8 Ohm secondary.  Standard 2-hole mounting, 79.4mm (3-1/8") center-to-center.  Standard blue-red-brown primary, green-black secondary wiring color code.   Download spec sheet here.

Read the history of the development of this transformer here!

Part #BJT8336

$69.95

Revisit™ OUTPUT TRANSFORMER, FENDER.  Replacement for Fender™ Champ, VibroChamp, Champion 600 and Bronco amps.  Equivalent to #125A35A & #022905.  X-Mount with mounting centers at 2 3/8".

Part #NSC022905

$44.95

Click on photo for
larger view

Replacement original style output transformer for most vintage Blackface and Silverface Fender Delxue and Deluxe Reverb amps with 25 watt output power. Replaces Fender part numbers 125A1A and 041318.

6600 Ohm Center-Tapped Primary, 8 Ohm secondary.  Standard 2-hole mounting, 79.4mm (3-1/8") center-to-center.  Standard blue-red-brown primary, green-black secondary wiring color code.

Part #NSC041318

$69.95

Click on photo for
larger view



W025130 Details.  Click on drawing for
more information.

Replacement 120V-125V power transformer for most Blackface and Silverface Fender amps with 20-25 watt output power. Replaces Fender part numbers 125P23B and 025130.  Used in the vintage Deluxe, Deluxe Reverb made before 1982, and the Tweed Tremolux (1955-1960) .   Has only 120/125V primary wiring, so this transformer is only for the United States, Canada, Bermuda and the Caribbean Islands.   As this transformer is a special order item, it is not returnable.

Part #W025130

$159.95

Click on photo for
larger view

W022798 Details.  Click on drawing for
more information.

Replacement power transformer for most Blackface and Silverface Fender amps with 40 watt or 50 watt power. Replaces Fender part numbers 125P5D, 125P5DX, 022798, 8087, and 022806  Used in vintage Bassman, Pro, Pro Reverb, Super and Super Reverb models.   Has multiple primary taps for various commercial power in all countries where we ship.   As this transformer is a special order item, it is not returnable.

Part #W022798

$119.95

Click on photo for
larger view

W022756 Details.  Click on drawing for
more information.

Replacement 120V-125V power transformer for most Blackface and Silverface Fender amps with 100 watt power. Replaces Fender part numbers 125P34A, 125P34AX, 022756, and 022764.  Used in vintage Fender Twin, Twin Reverb, Dual Showman, Dual Showman Reverb, Super 6 Reverb, Showman, Quad Reverb, PA-100, and Bassman 100 models made before 1976.   Has only 120/125V primary wiring, so this transformer is only for the United States, Canada, Bermuda and the Caribbean Islands.   As this transformer is a special order item, it is not returnable.

Part #W022756

$169.95

Click on photo for
larger view



W022723 Details.  Click on drawing for
more information.

Replacement 120V-125V power transformer for most Blackface and Silverface Fender amps with 25-30 watt output power. Replaces Fender part numbers 125P26A and 022723.  Used in the vintage Fender Model 30, Tremolux, Vibrolux and Vibrolux Reverb made before 1982.   Has only 120/125V primary wiring, so this transformer is only for the United States, Canada, Bermuda and the Caribbean Islands.   As this transformer is a special order item, it is not returnable.

Part #W022723

$139.95

Click on photo for
larger view




W022772 Details.  Click on drawing for
more information.

Replacement 120V-125V power transformer for most Blackface and Silverface Fender amps with 5 to 15 watt output power. Replaces Fender part numbers 125P1B and 022772.  Used in the vintage Bronco, Champ, Tweed 5F1 Champ, Princeton, Princeton Reverb, or Vibro Champ made before 1982.   Offers both 275V or 325V (650/550 VCT) B+ options for earlier or later breakup (your choice).  Has only 120/125V primary wiring, so this transformer is only for the United States, Canada, Bermuda and the Caribbean Islands.   As this transformer is a special order item, it is not returnable.

Part #W022772

$109.95

Click on photo for
larger view

$18.95

Click on photo for
larger view

Replacement filter choke for Fender™ Bassman, Bandmaster, Concert, Showman, Dual Showman, Pro Reverb, Super Reverb, Twin Reverb, Vibroverb, etc.  Not used with the Vibrolux - see the FC-194A choke for the Vibrolux.  Replaces Fender™ part number 125C1A, 022699 and 036486.   Inductance 4H, +/- 15%, DC current 90mA.  Vacuum impregnated with polyurethane varnish for quiet and long life operation.  For dimensions and technical specifications, click here.

Part #FC-194B

$33.95

Click on photo for
larger view

For vintage blackface and silverface Deluxe Reverb, Princeton Reverb, Twin Reverb, Pro Reverb, Super Reverb, Vibrolux Reverb, etc.   Equivalent to Fender™ #125A20B & #022921.   For vintage Mesa-Boogie™ models, including vintage Mark I through Mark IV, Subway Blues, Studio 22, Studio Caliber, Maverick, Lonestar Special, and many others .    Mesa Boogie™ part number 550185.  10" cut leads, X-Mount with 1 3/4" mounting centers.  Input impedance 14.5K ohms, output impedance 4 ohms.

Part #TGR-001

$20.95

Reverb transformer as found in the Fender™ 65 Twin Reverb Reissue, 65 Super Reverb Reissue, 65 Princeton Reverb Reissue, and 65 Deluxe Reverb Reissue.    Fender™ part number 0037099049.  10" leads with .187 faston connectors, X-Mount with 1 3/4" mounting centers.

Part #037099

$39.95

Kit contains 2 8-32 thread truss-head machine screws, 1/2 inch long, and 2 8-32 KEPS hex nuts with built-in locking washer.   The screws have combination heads for use a flat or Phillips screwdriver, and the screw heads are extra-wide at 3/8" diameter.

Designed for use with chassis holes of 5/32" or 3/16" (4mm or 5mm).

For mounting any of the above transformers which are designed with 2 mounting holes.

Part #TMH-832-2

$0.89

(for a set of 2 screws and 2 nuts)

Kit contains 4 8-32 thread truss-head machine screws, 1/2 inch long, and 4 8-32 KEPS hex nuts with built-in locking washer.   The screws have combination heads for use a flat or Phillips screwdriver, and the screw heads are extra-wide at 3/8" diameter.

Designed for use with chassis holes of 5/32" or 3/16" (4mm or 5mm).

For mounting any of the above transformers which are designed with 4 mounting holes.

Part #TMH-832-4

$1.69

(for a set of 2 screws and 2 nuts)
